24-Port Gigabit PoE+ Switch

TPE-TG240g (Version V4)

  • 24 x Gigabit PoE+ ports
  • 48Gbps switching capacity
  • 370W PoE power budget
  • Extend PoE+ signal up to 250m (820 ft.) at 10Mbps on ports 1 – 8
  • DIP switch supports VLAN port isolation and storm control
  • Smart Fans
  • Reduces equipment cost by delivering data and power over existing network cables
  • 1U 19” rack mountable metal housing with brackets included
  • Internal power supply
  • NDAA / TAA compliant (U.S. and Canada only)
NDAA/TAA Compliant
Coming Soon

TRENDnet’s 24-Port Gigabit PoE+ Switch, model TPE-TG240g, provides high-bandwidth performance, ease-of-use, and reliability. The IEEE 802.3at compliant switch features a sturdy 1U 19” rack mountable metal housing with mounting brackets included.

Installers and integrators can save on equipment costs and reduce installation time with TRENDnet’s unmanaged PoE+ switch by delivering up to 30W per port of PoE+ power and data over existing Ethernet cables. Easily network PoE devices, such as high-power wireless access points, cameras, digital signage, IPTV decoders, access controls, and more with this high-power PoE+ switch. Enable the DIP switch to extend the PoE+ signal up to 250m (820 ft.) at 10Mbps for long-distance PoE installations. Easily install this long-range PoE switch for reliable high-speed PoE networking.

TRENDnet PoE+ switch with multiple Ethernet ports connected to a dome security camera and a wireless access point using Ethernet cables that deliver both data and power, indicated by yellow lightning bolt icons.

PoE+

The unmanaged PoE+ switch features a 370W total PoE power budget, and supplies 24 Power over Ethernet devices with up to 30W per port.

Conceptual illustration of two laptops labeled Gigabit connected through a central network switch with arrows indicating bidirectional data flow. Surrounding the arrows are icons representing email, cloud storage, video, music, documents, and social media, suggesting high-speed data exchange across multiple services.

Gigabit Ports

Equipped with 24 high-speed gigabit ports and a full switching capacity, this unmanaged PoE+ switch is ready to take on the most demanding network applications.

Surveillance setup showing a security camera connected to a TRENDnet Gigabit PoE+ Switch via a 250-meter cable. The switch features multiple Ethernet ports with green highlights indicating PoE capability and includes status LEDs for power and network activity, emphasizing long-distance support for camera installations.

Long Range PoE+ Switch

Enable the DIP switch to extend a PoE+ signal up to 250m (820 ft.) at 10Mbps on ports 1 – 8.

TRENDnet switch with LED indicators, DIP switch, 24 Gigabit PoE+ ports, and power port. Below, an office layout shows a PoE camera outside, a server rack inside, multiple workstations, and a connected TPE-TG240g switch, illustrating centralized device management.

Easy Installation

No configuration needed, simply connect PoE+ network devices to the unmanaged gigabit PoE+ switch

PoE Power

The PoE+ switch supplies up to 30W of power per port with data over a single Ethernet cable to PoE and PoE+ devices

Gigabit Ports

Equipped with 24 high-speed gigabit ports and a full switching capacity, this unmanaged PoE+ switch is ready to take on the most demanding network applications

Long Range PoE+

Enable the DIP switch to extend a PoE+ signal up to 250m (820 ft.) at 10Mbps on ports 1 – 8

Port Isolation

To prevent traffic from being sent between isolated ports, the DIP switch enables port isolation on ports 1 – 23

Strom Control

A broadcast storm control threshold value of 128kbps will be applied to incoming packets on all ports

PD Alive Alert

Automatically check if powered devices connected to the switch are currently active or not on all ports

Rackmount Design

With a sturdy metal housing and included rackmount brackets, this switch is well-suited for 19” 1U rack installations.

Jumbo Frame

Sends larger packets, or Jumbo Frames (up to 9KB) for increased performance

Smart Fans

Smart fans saves energy by auto-adjusting the fan speed and use based on cooling needs

Internal Power Supply

100-240VAC, 50/60Hz internal universal switching power supply

LED Indicators

LED indicators convey port status

Standards
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3ab
  • IEEE 802.3af
  • IEEE 802.3at
Device Interface
  • 24 x Gigabit PoE+ ports (10Mbps/100Mbps/1000Mbps)
  • DIP switch
  • LED indicators
Performance
  • Data RAM Buffer: 512KB
  • Switch Fabric: 48Gbps
  • MAC Address Table: 8K entries
  • Forwarding rate: 35.7Mpps (64-byte packet size)
  • Jumbo Frame: 9KB
Power
  • Input: 100 – 240V AC, 50/60Hz, internal power supply
  • Max. consumption: 36W (no PD)
PoE
  • PoE budget: 370W
  • PoE Mode A: Pin 1, 2 -; 3, 6 +
  • Over current protection
  • Short circuit protection
DIP Switch
  • Flow Control On (default) / Off
  • Port Isolation and Storm Control On / Off (default)
  • Long Range PoE+ On / Off (default)
  • PD Alive Alert On / Off (default)
Fan/Acoustics
  • Quantity: 2
  • Smart fans
  • Max. noise Level: 48.9dB
MTBF
  • 916, 712 hours @ 25° C
Operating Temperature
  • 0° – 50° C (32° - 122° F)
Operating Humidity
  • Max. 95% non-condensing
Dimensions
  • 440 x 210 x 44mm (17.3 x 8.3 x 1.8 in.)
Weight
  • 3kg (6.6 lbs.)
Certifications
  • CE
  • FCC
  • UL
Warranty
  • 3 year

PACKAGE CONTENTS
  • TPE-TG240g
  • Rack mount kit
  • Power cord (1.8m/6 ft.)

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
