You can use any port on the TE100-S5 to connect to an existing network.
The TE100-S5 is a switch. It is not a router and will not allow you to share your Internet connection. You will need a router to share Internet. The TE100-S5 can be used to expand the amount of ports on your existing router or network....
No.
Please check the following:
Please make sure that the cable is seated properly on both ends.
Make sure that you are using a known working cable.
If possible please try plugging in a known working device in the port you are having issues with to see if the problem follows the switch or the de...
Standards | - IEEE 802.3
- IEEE 802.3u
- IEEE 802.3x
- IEEE 802.3az
|
Interface do Dispositivo | - 5 portas 10/100 Mbps Ethernet
- LED Indicadores
- Adaptador Externo de Tensão
|
Taxa de Transferência de Dados | - Ethernet: 10 Mbps (half-duplex), 20 Mbps (full-duplex)
- Fast Ethernet: 100 Mbps (half-duplex), 200 Mbps (full-duplex)
|
Performance | - Buffer de dados RAM: 448 Kbits
- Estrutura do Switch: 1 Gbps
- Tabela de endereços MAC: 1K entradas
- Taxas de encaminhamento: 0,7 Mpps (tamanho de pacote 64-byte)
|
Características Especiais | - Tecnologia GREENnet de poupança de energia
|
Alimentação | - Entrada: 100-240 V AC, 50/60 Hz, 0.2 A
- Saída: 5 V DC, 1 A
- Consumo Máx: 1.1 Watts
|
Temperatura de Operação | - 0°C – 50 °C (32° - 122 °F)
|
Umidade de Operação | - Máx. 90% (sem-condensação)
|
Dimensões | - 97 x 75 x 28 mm (3,8 x 3 x 1,1 polegadas)
|
Peso | |
Certificações | |
Garantia | |
CONTEÚDO DA EMBALAGEM |
- TE100-S5
- Guia de Instalação Rápida
- Fontes de Tensão (5 V DC, 1 A)
|
* Economia máxima de energia comparado com switches trendnet convencionais.
Todas as referências à velocidade são apenas para fins comparativos. As especificações, tamanho e formato do produto estão sujeitos a alterações sem aviso prévio, e a aparência real do produto pode ser diferente da descrita aqui.
