You will need to be running Cat-6a or higher cabling for 10GBASE-T.
Please check your network adapter’s specification and make sure that it supports 2.5 Gbps.
Also, check if your network cable is Cat-5e or higher.
...
All ports on the TEG-S708 support Auto-MDIX. All ports can be used as an uplink port.
To share an Internet connection you will need a Router. The TEG-S708 can be utilized to expand the available ports on your existing Router or network....
The TEG-S708 supports jumbo frames up to 12KB.
The TEG-S708 is a non-manageable Switch. It is not configurable.
A Switch cannot share an IP address provided by your ISP with multiple devices. You will need a Router to share your Internet service with multiple devices. The Switch can be used to expand the amount of available ports on your network....
Padrões | - IEEE 802.3
- IEEE 802.3u
- IEEE 802.3x
- IEEE 802.3z
- IEEE 802.3ab
- IEEE 802.3an
- IEEE 802.3bz
|
Interface | - 8 x portas 10GBASE-T (100Mbps/1Gbps/2.5Gbps/5Gbps/10G)
- LED indicators
|
Intervalo de transferência de dados | - Ethernet: 10 Mbps (half-duplex), 20 Mbps (full-duplex)
- Fast Ethernet: 100 Mbps (half-duplex), 200 Mbps (full-duplex)
- Gigabit Ethernet: 2000 Mbps (full-duplex)
- 2.5 Gigabit: 5Gbps (full duplex)
- 5 Gigabit: 10Gbps (full duplex)
- 10 Gigabit: 20Gbps (full duplex)
|
Desempenho | - Capacidade de Comutação: 160Gbps
- Buffer de Dados RAM: 1.5MB
- MAC Tabela de Endereços: entradas de 16 K
- Taxa de encaminhamento: 115.9, Mpps (tamanho do pacote de 64 bytes)
- Jumbo Frames: 12KB
|
Características especiais | |
Alimentação | - Entrada: 100 - 240V AC, 50/60Hz, 5.4A
- Consumo máximo: 36,8W
|
Ventoinhas/acústica | - Quantidade: 1
- Nível máximo de ruído: 52.2 dBA
|
MTBF | |
Temperatura de operação | - 0° – 40° C (32° – 104° F)
|
Umidade de operação | |
Dimensions (L x W x H) | - 326 x 230 x 43mm (12,83 x 9,05 x 1,69 in.)
|
Peso | |
Certificações | |
Garantia | |
CONTEÚDO DA EMBALAGEM |
- TEG-S708
- Guia de Instalação Rápido
- Cabo de energia (1,5m / 4,9 pés)
- Kit Rack Mount
|
Todas as referências à velocidade são apenas para fins comparativos. As especificações, tamanho e formato do produto estão sujeitos a alterações sem aviso prévio, e a aparência real do produto pode ser diferente da descrita aqui.
