GREENnet technology reduces power consumption by up to 70% when:*
Ethernet ports are not in use
Connected devices are turned off
Connected device are in power-saving modes
Based on Ethernet cable length
GREENnet technology requires feedback from the cable and the attached device. Please...
The TEG-S50g and TEG-S80g have Jumbo Frame support up to 9216Bytes
The TEG-S50g and TEG-S80g carry a 3 year limited warranty. Warranty disclaimer included with the product and available at www.TRENDnet.com....
The TEG-S50g and TEG-S80g are non-manageable switches. They are not configurable.
Power
Green: Power successfully applied to the switch
Not illuminated: No active power to the switch
LINK/ACT
Green (Solid): Successful link to a network device
Green (Blinking): Indicates network activity
Not illuminated: No physical connection to the port
100/1000M (T...
To share an Internet connection you will need a router. The switch can be utilized to expand the available ports on your existing router or network. ...
GREENnet technology reduces power consumption by up to 40% by turning off unused ports and intelligently providing power depending on the length of the Ethernet cable connected to active ports....
Hardware |
Standards | - IEEE 802.3 10Base-T
- IEEE 802.3u 100Base-TX
- IEEE 802.3ab 1000Base-T
- IEEE 802.3x Flow Control
- IEEE 802.3az Energy Efficient Ethernet
|
Network Media | - Ethernet: Cat. 3,4,5, up to 100m
- Fast Ethernet: Cat. 5, up to 100m
- Gigabit Ethernet: Cat. 5, 5e,6, up to 100m
|
Data Rate | - Ethernet: 10Mbps/20Mbps (half/full-duplex)
- Fast Ethernet: 100Mbps/200Mbps (half/full-duplex)
- Gigabit Ethernet: 2000Mbps (full-duplex)
|
Protocol / Topology | |
Power Consumption | |
Switch Fabric | - 10Gbps forwarding capacity
|
Interface | - 5 x 10/100/1000Mbps Auto-MDIX RJ-45 ports
|
Data RAM Buffer | |
Filtering Table | |
Jumbo Frame Support | |
Diagnostic LEDs | |
Power Adapter | - 5V DC, 1A external power adapter
|
Dimension | - 116 x 25 x 70mm (4.57 x 0.98 x 2.76 in.)
|
Weight | |
Temperature | - Operating: 0° ~ 40° C (32° ~ 104° F)
- Storage: -10° ~ 70° C (14° ~ 158° F)
|
Humidity | - Max. 90% (non-condensing)
|
Certifications | |
PACKAGE CONTENTS |
- TEG-S50g
- Multi-Language Quick Installation Guide
- Power Adapter (5V DC, 1A)
|
All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
