| Standards | - IEEE 802.3
- IEEE 802.3u
- IEEE 802.3x
- IEEE 802.3ab
- IEEE 802.3af
- IEEE 802.3at
|
|---|
| Device Interface | - 8 x Gigabit PoE+ ports (10Mbps / 100Mbps / 1000Mbps)
- LED indicators
|
|---|
| Performance | - Packet Buffer: 128KB
- Switch Fabric: 16Gbps
- MAC Address Table: 4K entries
- Forwarding rate: 11.9Mpps (64-byte packet size)
- Jumbo Frame: 9K
|
|---|
| Power | - Input: 100-240V AC, 50/60 Hz 1.2A
- Output: 55V DC, 1.67A
- Max. consumption: 5.18W (no PD connected)
|
|---|
| PoE | - PoE budget: 65W
- PoE Mode A: Pins 1, 2, 3, and 6 for power-
|
|---|
| MTBF | - 1, 141, 451 hours @ 25° C
|
|---|
| Operating Temperature | - 0° – 40° C (32° – 104° F)
|
|---|
| Operating Humidity | |
|---|
| Dimensions | - 154 x 85 x 26mm (6 x 3.35 x 1.02 in.)
|
|---|
| Weight | |
|---|
| Certifications | |
|---|
| Warranty | |
|---|
PACKAGE CONTENTS |
- TPE-TG82g
- Quick Installation Guide
- Power Brick (55V DC, 1.3A)
- Power cord
|
All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
