1-Port KVM Switch over IP

TK-IP101   (Version 1.0R)

  • Manage multiple servers from your network or remotely from any Internet connection
  • IP-based remote control server management for Windows and Java-based clients
  • An intuitive Web user interface provides control from BIOS level up to OS based applications

DISCONTINUED PRODUCT

The TK-IP101 (Version 1.0R) has been discontinued. For a list of discontinued products, click here.

Utility

Utility Viewer
Filename: Utility_TK-IP101-IP_Veiwer.zip
SHA-1 Checksum: 3564A38311991C507E0337BFBE2B46C5E8C4CB9C
Date: 7/25/2017
File Size: 1.08 MB
Download

Firmware

Firmware

TK-IP101 f/w version 2.6.21

Date: December 27, 2008

Release Note:

1. Fix issue for brightness level in viewer utility.


Filename: FW_TK-IP101-2.6.21.zip
SHA-1 Checksum: 834E7576B6D84B9C373AD61AB93DC9B0EE928044
Date: 7/25/2017
File Size: 5.55 MB
Download

Datasheet

Datasheet (English)
Filename: EN_spec_TK-IP101(v1.0R).pdf
Date: 2/14/2014
File Size: 972.10 KB
Download Email
Datasheet (Français)
Filename: FR_spec_TK-IP101(v1.0R).pdf
Date: 2/14/2014
File Size: 985.80 KB
Download Email
Datasheet (Deutsch)
Filename: GE_spec_TK-IP101(v1.0R).pdf
Date: 2/14/2014
File Size: 988.26 KB
Download Email
Datasheet (Español)
Filename: SP_spec_TK-IP101(v1.0R).pdf
Date: 2/14/2014
File Size: 981.47 KB
Download Email
Datasheet (Pусский)
Filename: RU_spec_TK-IP101(v1.0R).pdf
Date: 2/14/2014
File Size: 949.90 KB
Download Email

Quick Installation Guide

Quick Installation Guide (English)
Filename: EN_QIG_TK-IP101.pdf
Date: 6/3/2008
File Size: 1,023.06 KB
Download
Quick Installation Guide (Français)
Filename: FR_QIG_TK-IP101.pdf
Date: 6/3/2008
File Size: 1,015.22 KB
Download
Quick Installation Guide (Deutsch)
Filename: GE_QIG_TK-IP101.pdf
Date: 6/3/2008
File Size: 1,008.51 KB
Download
Quick Installation Guide (Português)
Filename: PO_QIG_TK-IP101.pdf
Date: 6/3/2008
File Size: 1.42 MB
Download
Quick Installation Guide (Español)
Filename: SP_QIG_TK-IP101.pdf
Date: 6/3/2008
File Size: 1,016.22 KB
Download
Quick Installation Guide (Pусский)
Filename: RU_QIG_TK-IP101.pdf
Date: 6/3/2008
File Size: 1.21 MB
Download
Quick Installation Guide (Eesti)
Filename: EST_QIG_TK-IP101.pdf
Date: 6/3/2008
File Size: 1.44 MB
Download

User's Guide

User's Guide (English)
Filename: UG_TK-IP101.pdf
Date: 7/23/2008
File Size: 5.10 MB
Download

Product Images

TK-IP101 Product Photo (JPEG Image 1)
JPEG Image
File Size: : 262.68 KB
Date: : 6/3/2008
Download
TK-IP101 Product Photo (JPEG Image 2)
JPEG Image
File Size: : 222.34 KB
Date: : 6/3/2008
Download
TK-IP101 Product Photo (JPEG Image 3)
JPEG Image
File Size: : 232.21 KB
Date: : 6/3/2008
Download
TK-IP101 Product Photo (TIFF Image 4)
TIFF Image
File Size: : 2.66 MB
Date: : 6/3/2008
Download
TK-IP101 Product Photo (TIFF Image 5)
TIFF Image
File Size: : 2.22 MB
Date: : 6/3/2008
Download
TK-IP101 Product Photo (TIFF Image 6)
TIFF Image
File Size: : 2.37 MB
Date: : 6/3/2008
Download
ROHS compliant Non-Disposable
Is this KVM HDCP compliant?
Unfortunately this KVM is not an HDCP compliant device.
Hardware
Number Of Server Ports
  • 1 X
Server Or KVM Port Connectors
  • 1x HDB 15-Pin Male + Special Cable Assembly Providing VGA, PS/2 Mouse And PS2 Keyboard Connectors.
  • 1 x USB Type B
Remote Connections
  • Multiple Connections [Shared/Private/View Only Session]
Viewer Session
  • Shared/View Only – Multiple Users/Private – 1 User
Local Console Connectors
  • 1 × PS/2 Keyboard 6-Pin Mini Din Female
  • 1 × PS/2 Mouse 6 Pin Mini Din Female
  • 1 × VGA HDB 15-Pin Female
PC Port Connectors
  • 1 X HDB15 (Integrated With PS/2 Keyboard And PS/2 Mouse
  • 1 X USB Type B (For USB Keyboard And USB Mouse)
Digital Connector
  • Rj-45
Ethernet Interface
  • 10/100 Base-T Connection With Auto-Sensing
Serial Console Port (Front)
  • RJ-12 Connector/115200 Bps Max - Used Only For Console Management
Serial Control Port (Back)
  • RJ-12/1Mpbs High-Speed Serial For Connect To External Modem/Power Control Device
Server Control Remote Interface
  • Win32 Viewer/JAVA Viewer
Management
  • With Any Browser Connected To The Embedded Web Server Via HTTPS Connection
Supported OS
  • Windows 98(SE)/ME/2000/XP/2003 Server/Vista/7/8/8.1
Encryption
  • SSL, Encryption With 256-Bit Ephemeral Keys
  • User Authentication Based On Password And PKI Certificates
Video Resolution
  • 1600 × 1200 Max.
Keyboard Emulation
  • PS/2 And USB
Mouse Emulation
  • PS/2 and USB
Remote Power On/Off
  • Yes*
Power Input
  • DC 9V 2A
Operation Temperature
  • 0 ~ 50°C
Storage Temperature
  • - 20 ~ 60°C
Humidity
  • 0~90% RH, Non-Condensing
Housing
  • Metal/0U
Dimension (L x W x H)
  • 16 x 11.5 x 2.5 cm
Safety/EMI Certification
  • FCC, CE

PACKAGE CONTENTS
  • TK-IP101
  • Multi-Language Quick Installation Guide
  • CD-ROM (User's Guide)
  • 1 x PS/2 KVM Cable (1.5 m/5 ft.)
  • 1 x USB Type B Cable (1m/3.3 ft.)
  • 1 x RJ-12 to Female Serial Port Cable (1m/3.3 ft.)
  • 1 x RJ-12 to male Serial Port Cable (1m/3.3 ft.)
  • 1 x RJ-12 to Parallel Port Cable (1m/3.3 ft.)
  • 1 x Power adapter (9 V DC 2 A)

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
