8-Port Gigabit Desktop Switch

TEG-S83   (Version v1.0R)

  • Plug and play installation
  • 8 x Gigabit ports
  • 16Gbps switching capacity
  • Sturdy metal switch
  • Fanless design
  • NDAA / TAA compliant (U.S. and Canada only)
  • Lifetime Warranty*
NDAA/TAA Compliant
Datasheet
Datasheet (English)
Filename: EN_datasheet_TEG-S83_(v1.0R).pdf
Date
4/20/2022
File Size
747.93 KB
Download Email
Datasheet (Français)
Filename: FR_datasheet_TEG-S83_(v1.0R).pdf
Date
4/20/2022
File Size
880.82 KB
Download Email
Datasheet (Deutsch)
Filename: GE_datasheet_TEG-S83_(v1.0R).pdf
Date
4/20/2022
File Size
591.97 KB
Download Email
Datasheet (Português)
Filename: PO_datasheet_TEG-S83_(v1.0R).pdf
Date
4/20/2022
File Size
857.58 KB
Download Email
Datasheet (Español)
Filename: SP_datasheet_TEG-S83_(v1.0R).pdf
Date
4/20/2022
File Size
846.10 KB
Download Email
Datasheet (Pусский)
Filename: RU_datasheet_TEG-S83_(v1.0R).pdf
Date
4/20/2022
File Size
794.75 KB
Download Email
Datasheet (Italiano)
Filename: IT_datasheet_TEG-S83_(v1.0R).pdf
Date
4/20/2022
File Size
837.53 KB
Download Email
Quick Installation Guide
Quick Installation Guide (QIG)
Filename: lineart qig_TEG-S83_S51(v1).pdf
Date
4/20/2022
File Size
3.45 MB
Download
Product Images

PNG Image
File Size: 4.55 MB
Date: 7/8/2022
Download

PNG Image
File Size: 2.92 MB
Date: 7/8/2022
Download

PNG Image
File Size: 2.85 MB
Date: 7/8/2022
Download

PNG Image
File Size: 4.19 MB
Date: 7/8/2022
Download
How do I configure the TEG-S83?
The TEG-S83 is a non-manageable Switch. It is not configurable.
Is there an uplink port on the TEG-S83?
All ports on the TEG-S83 support Auto-MDIX. All ports can be used as an uplink port.
Does the TEG-S83 support jumbo frames?
The TEG-S83 supports jumbo frames up to 9 KBytes.
Why can only one computer connected to the TEG-S83 go online?
To share an Internet connection you will need a Router. The TEG-S83 can be utilized to expand the available ports on your existing Router or network....
Standards
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3ab
Device Interface
  • 8 x Gigabit ports
  • LED indicators
Data Transfer Rate
  • Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
  • Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
  • Gigabit: 2000Mbps (full duplex)
Performance
  • Switching Capacity: 16Gbps
  • RAM Buffer: 192KB
  • MAC Address Table: 4K entries
  • Forwarding Rate: 11.9Mpps (64-byte packet size)
  • Jumbo Frames: 9KB
Power
  • Input: 100 – 240V AC, 50/60 Hz, 0.2A
  • Output: 5 V DC, 1A external power adapter
  • Max. Consumption: 3.2W
Fan/Acoustics
  • Fanless design
MTBF
  • 1,451,740 hours
Operating Temperature
  • 0° – 40° C (32° – 104° F)
Operating Humidity
  • Max. 90% non-condensing
Dimensions (L x W x H)
  • 160 x 25 x 109mm (6.29 x 0.98 x 4.29 in.)
Weight
  • 414g (14.6 oz.)
Certifications
  • FCC
  • CE
Warranty
PACKAGE CONTENTS
  • TEG-S83
  • Quick Installation Guide
  • Power Adapter (5V DC, 1A)

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
