6-Port Multi-Gig Switch

TEG-S562   (Version V2)

   Select Another Version
  • 4 x 2.5GBASE-T ports
  • 2 x 10G SFP+ ports
  • 60Gbps switching capacity
  • Compatible with existing Cat5e or better cabling
  • Backward compatible SFP speeds of 1000Mbps
  • Fanless design eliminates noise
  • Wall mountable for installation flexibility
  • IEEE 802.3bz (2.5G) and IEEE 802.3ae (10G SFP+) compliant
  • NDAA / TAA compliant (U.S. and Canada only)
  • Lifetime Warranty*
NDAA/TAA Compliant
Standards
  • IEEE 802.3ab
  • IEEE 802.3ae
  • IEEE 802.3an
  • IEEE 802.3bz
  • IEEE 802.3x
Device Interface
  • 4 x 2.5G ports (100Mbps/1Gbps/2.5Gbps)
  • 2 x 10G SFP+ ports (1Gbps/10Gbps)
  • LED indicators
Performance
  • Switch fabric: 60Gbps
  • RAM buffer: 1MB
  • MAC address table: 16K entries
  • Jumbo frames: 10KB
  • Forwarding rate: 44.64Mpps (64-byte packet size)
Power
  • Input: 90 – 264V AC, 47/63 Hz
  • Output: 12V, 1A
  • Max. consumption: 5.86W
MTBF
  • 1,079,150 hours @25°
Fan / Acoustics
  • Fanless
Operating Temperature
  • 0° – 40° C (32° – 104° F)
Operating Humidity
  • Max. 90% non-condensing
Dimensions
  • 120 x 75 x 26mm (4.7 x 2.95 x 1 in.)
Weight
  • 258g (9.1 oz.)
Certifications
  • CE
  • FCC
  • LVD
Warranty

PACKAGE CONTENTS
  • TEG-S562
  • Power adapter (12V, 1A)

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
