SecurView Wireless Day/Night Network Camera

TV-IP312W   (Version A1.0R)

  • Excellent night infrared recording and 2-way audio to listen and talk through the camera
  • No need for an Ethernet connection, video is transmitted over an encrypted wireless signal
  • Superb image quality with MPEG-4 compression
  • View streaming video, hear sounds, verbally respond and record from any Internet connection

DISCONTINUED PRODUCT

The TV-IP312W (Version A1.0R) has been discontinued. It has been replaced by the TV-IP1314PI (Version v1.0R). For a list of discontinued products, click here.

Utility

Filename: Camera_Utility.zip
SHA-1 Checksum: 679B96BB0EF1F0763DC23D01D670C8FC4E943004
Date: 10/27/2017
File Size: 20.98 MB

Firmware

DO NOT upgrade firmware on any TRENDnet product using wireless connection.
Firmware upgrade over wireless connection may damage the product. Please perform firmware upgrade with "wired" network connection only


Firmware Version: V1.1.1 build 75
Release Date: 4/2013

Note:

  1. Upload.asp removed.
  2. Updated save configuration file encryption type.
  3. Set RTSP default authentication to "digest".

Note:

  • Please do not save the camera's configuration file from the old firmware and restore it after the firmware upgrade.
  • After a successful firmware upgrade, please reset the camera to factory default and reconfigure the camera. We strongly recommend that you change the camera's administrator's account password.
  • Please ensure you update to firmware version 1.1.1 build 75 from version 1.1.0 build 67 or higher. If you have an older firmware, please update to version 1.1.0 build 67 first.

Filename: FW_TV-IP312W_A1.x(1.1.1.75).zip
SHA-1 Checksum: 2DC24EA94AB0B34F1069677393D1CCF77814131D
Date: 7/26/2017
File Size: 4.45 MB
DO NOT upgrade firmware on any TRENDnet product using wireless connection.
Firmware upgrade over wireless connection may damage the product. Please perform firmware upgrade with "wired" network connection only


Firmware Version: V1.1.0 build 67
Release Date: 2/2011

Note:

  1. Improve audio quality for live streaming
  2. Change the member.Dyndns.org to www.Dyndns.com .
  3. Change default time zoom to US pacific time
  4. Addressed watchdog issue, improved camera stability
  5. Fixed IR control Problem.

Note: If you have firmware version 1.1.0 build 66 or older, please update to firmware version 1.1.0 build 67 first. After you have updated the firmware to version 1.1.0 build 67, you can update the firmware to version 1.1.1 build 74.

Filename: FW(TV-IP312W(1.1.0.67).zip
SHA-1 Checksum: 0211147503B4B51810F0332ACFA191E6A02D0B7B
Date: 7/26/2017
File Size: 4.17 MB

Datasheet

Filename: EN_Spec_TV-IP312W(A1.0R).pdf
Date: 12/20/2013
File Size: 966.25 KB
Filename: FR_Spec_TV-IP312W(A1.0R).pdf
Date: 12/20/2013
File Size: 971.59 KB
Filename: GE_Spec_TV-IP312W(A1.0R).pdf
Date: 12/20/2013
File Size: 975.39 KB
Filename: SP_Spec_TV-IP312W(A1.0R).pdf
Date: 12/20/2013
File Size: 975.93 KB
Filename: RU_Spec_TV-IP312W(A1.0R).pdf
Date: 12/20/2013
File Size: 2.10 MB
Filename: ITA_Spec_TV-IP312W(A1.0R).pdf
Date: 12/20/2013
File Size: 952.74 KB

Quick Installation Guide

Filename: EN_Web_QIG_TV-IP212_212W_312_312W(A1.0R).pdf
Date: 3/1/2010
File Size: 987.86 KB
Filename: FR_Web_QIG_TV-IP212_212W_312_312W(A1.0R).pdf
Date: 3/1/2010
File Size: 988.85 KB
Filename: GE_Web_QIG_TV-IP212_212W_312_312W(A1.0R).pdf
Date: 3/1/2010
File Size: 991.75 KB
Filename: PO_QIG_TV-IP212_212W_312_312W.pdf
Date: 10/6/2007
File Size: 976.11 KB
Filename: SP_Web_QIG_TV-IP212_212W_312_312W(A1.0R).pdf
Date: 3/1/2010
File Size: 988.59 KB
Filename: RU_Web_QIG_TV-IP212_212W_312_312W(A1.0R).pdf
Date: 3/1/2010
File Size: 1.75 MB
Filename: EST_QIG_TV-IP212_212W_312_312W.pdf
Date: 3/21/2008
File Size: 744.32 KB

User's Guide

Filename: UG_TV-312_312W(A1).pdf
Date: 3/11/2010
File Size: 3.40 MB

Product Images

JPEG Image
File Size: : 360.66 KB
Date: : 9/10/2007
JPEG Image
File Size: : 351.74 KB
Date: : 9/10/2007
JPEG Image
File Size: : 270.80 KB
Date: : 9/10/2007
TIFF Image
File Size: : 4.26 MB
Date: : 9/10/2007
TIFF Image
File Size: : 4.19 MB
Date: : 9/10/2007
TIFF Image
File Size: : 3.43 MB
Date: : 9/10/2007
JPEG Image
File Size: : 303.04 KB
Date: : 9/10/2007
TIFF Image
File Size: : 2.22 MB
Date: : 9/10/2007
ROHS compliant WEEE crossed-out bin symbol.
Camera Specifications
Image Sensor
Sensor 1/4" Color CMOS Sensor
Resolution 640 x 480 Pixel
Fixed Lens f: 4.6mm, F: 2.8 (IR Lens)
Viewing Angle 60 Degree
Minimum Illumination 0.5Lux @ F2.0
Audio
Microphone Input Internal Omni-Directional
Sensitivity: -48dB + 3dB
Response Frequency:
50 ~ 16000Hz
Audio Output 3.5mm Speaker Output Jack
Format PCM/AMR (Mono)
Video/Image Setting
Video Format MPEG4(Simple Profile), MJPEG, 3GPP
Image Frame Rate 30fps @VGA, QVGA, QQVGA
Frame Rate Setting 1 ~ 30fps
Compression Ration Setting 5 Levels
Resolution 640 x 480, 320 x 240, 160 x 120
Exposure Control, White Balance, Gain Control Automatic
Image Setting Adjustable Brightness, Contrast, Saturation
Flip Images Vertical/Horizontal
Light Frequency 50Hz, 60Hz or Outdoor
Communication
LAN 10/100Mbps Auto MDIX
Protocol HTTP, FTP, TCP/IP, UDP, ICMP, DHCP, NTP, DNS, DDNS, SMTP, PPPoE, UPnP, RTP, RTSP, RTCP
Hardware Specifications
System
CPU ARM9 base
RAM 32Mbyte SDRM
ROM 8Mbyte Nor Flash
OS Linux
System Requirement (Web Configuration)
CPU Pentium III 350MHz or above
Memory Size 128MB or above
Resolution 800 x 600 or above
Browser Internet Explorer 6.0 or above
Supported OS Windows 7, Vista, XP, 2000
System Requirement (SecurView™ Software)
CPU Pentium 4 1GHz or above
Memory Size 512MB or above
Resolution 1024 X 768 or above
Supported OS Windows 7 (32-bit), Vista (32-bit), XP (32-bit), 2000
Physical /Environment
Dimension 70 x 100 x 57mm (2.67 x 3.94 x 2.95 in.)
Weight
  • Camera: 170g (6 oz.)
  • Stand: 135g (4.76oz.)
Power 5VDC, 2.5A External Power Adapter
Power Consumption 8 Watts (Max)
LEDs Power (Orange), Link (Green)
LED Enable/Disable Support
IR Wavelength 850nm
Temperature
  • Operation: 0ºC ~ 45ºC (32ºF ~ 113ºF)
  • Storage : -10ºC ~ 60ºC (14ºF ~ 140ºF)
Wireless
Standard IEEE 802.11b/g
Security 64/128-bit WEP, WPA-PSK, WPA2-PSK
Antenna 2dBi Detachable Reverse SMA Connector
Other
USB Port USB 1.1 (Type 1)
Up to 500mA Power Device with FAT16/32 Format
IR Sensor
(minimum lux)
Normal mode: 2~2.5 lux
Night mode on: 0.5 lux
IR on: 0 lux
Light sensor activates the IR LED on/off: 5~10 lux

PACKAGE CONTENTS

  • TV-IP312W
  • Multi-Language Quick Installation Guide
  • CD-ROM (Utility & User's Guide)
  • Camera stand
  • Cat.5 Ethernet Cable (1.8m/5.9ft.)
  • Power adapter (5VDC, 2.5A)

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
