Hardware |
Standards : | - Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX) , IEEE 802.3af PoE
- Wireless: IEEE 802.11b (11Mbps), IEEE 802.11g (54Mbps), IEEE 802.1x, IEEE 802.11d
|
LED Indicators: | Power, Status, LAN and WLAN |
Console Port: | RS232 Port (DB9) |
Protocols: | TCP/IP, NetBEUI, ARP, DHCP Client, HTTP, NTP, RADIUS, WINS, Telnet, FTP, HTTPs, SSL |
CPU/Radio/RAM/Flash: | Atheros 2312/ Atheros 2112/ 8Mbytes/ 2Mbytes |
Client Support: | DHCP Client, WINS Client, Radius Client |
Power Source: | 24V DC, 500mA External Power Adapter or PoE Connection |
Dimensions: | (LxWxH) 141 x 100 x 27 mm (5.5 x 3.9 x 1.06 inches) (without antennas) |
Weight: | 0.35 kg. (12.5 oz.) |
Temperature Operating: | 0°~ 40°C (32°F~ 104°F) |
Storage: | -10°~ 70°C (14°F~ 158°F) |
Humidity: | Max. 95% (non-condensing) |
Certification: | FCC, CE |
Wireless |
Module Technique: | 802.11b: CCK, DQPSK, DBPSK ; 802.11g: OFDM Frequency Range 2.4 ~ 2.497 GHz |
Modes: | Access Point, AP Client/Repeater, Bridge (PTP or PTMP) |
Data Rate (auto fallback): | - 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps
- 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps
|
Channels: | 1~14 Channels (Universal Support) |
Security: | 64/128/152-bit (WEP), WPA-PSK/WPA2-PSK, WPA/WPA2-RADIUS |
Management: | Web Browser (HTTP or HTTPS); SNMP V2, V2C; Telnet & CLI |
Antenna: | 1 x 2dBi External Detachable Dipole Antenna with Female Reverse SMA connector |
Output Power Adjustable: | Full (18dBm), Half (15dBm), Quarter (12dBm), Eighth (9dBm), Minimum (6dBm) |
Receiving Sensitivity: | 11Mbps 10 – 5 BER @ -86 dBm (typical) 54Mbps 10 – 5 BER @ -71 dBm (typical) 108Mbps 10 – 5 BER @ -68 dBm (typical) |
