AC2600 StreamBoost™ MU-MIMO WiFi Router (Certified Refurbished)

RB-TEW-827DRU   (Version v1.0R)

  • Quad-stream AC2600: 1733 Mbps WiFi AC + 800 Mbps WiFi N bands
  • MU-MIMO boosts performance in a busy home
  • StreamBoost Low latency gaming/voice prioritization
  • High performance 1.4 GHz dual-core processor
  • Pre-encrypted WiFi for your convenience
  • All Gigabit wired ports
  • USB 3.0 share ports
  • Detachable high gain antennas

Firmware

DO NOT upgrade firmware on any TRENDnet product using wireless connection.
Firmware upgrade over wireless connection may damage the product. Please perform firmware upgrade with "wired" network connection only

Model:TEW-827DRU
Hardware Version: v1.0R
------------------------------------------

Firmware Version:1.06b01
Release Date: 7/2020
Release Note:

  • -Fixed security vulnerabilities

Filename: FW_TEW-827DRU_v1(1.06b01).zip
SHA-1 Checksum: FEB1327CAC3DE097C26143CA47C947FC6970BF0C
Date: 7/13/2020
File Size: 23.96 MB

Datasheet

Filename: EN_datasheet_TEW-827DRU(v1.0R).pdf
Date: 1/10/2017
File Size: 5.33 MB
Filename: FR_datasheet_TEW-827DRU(v1.0R).pdf
Date: 12/15/2015
File Size: 5.40 MB
Filename: GE_datasheet_TEW-827DRU(v1.0R).pdf
Date: 12/15/2015
File Size: 5.33 MB
Filename: PO_datasheet_TEW-827DRU(v1.0R).pdf
Date: 12/15/2015
File Size: 5.55 MB
Filename: SP_datasheet_TEW-827DRU(v1.0R).pdf
Date: 12/15/2015
File Size: 5.22 MB
Filename: RU_datasheet_TEW-827DRU(v1.0R).pdf
Date: 12/15/2015
File Size: 5.54 MB
Filename: IT_datasheet_TEW-827DRU(v1.0R).pdf
Date: 12/15/2015
File Size: 5.42 MB

Quick Installation Guide

Filename: EN_Web_TEW-827DRU(V1.0R).pdf
Date: 11/30/2015
File Size: 2.66 MB
Filename: FR_Web_TEW-827DRU(V1.0R).pdf
Date: 12/3/2015
File Size: 2.65 MB
Filename: GE_Web_TEW-827DRU(V1.0R).pdf
Date: 11/23/2015
File Size: 2.60 MB
Filename: PO_Web_TEW-827DRU(V1.0R).pdf
Date: 11/23/2015
File Size: 1.22 MB
Filename: SP_Web_TEW-827DRU(V1.0R).pdf
Date: 11/23/2015
File Size: 2.60 MB
Filename: RU_Web_TEW-827DRU(V1.0R).pdf
Date: 12/3/2015
File Size: 2.60 MB
Filename: ITA_Web_TEW-827DRU(V1.0R).pdf
Date: 12/3/2015
File Size: 2.60 MB
Filename: POL_Web_TEW-827DRU(V1.0R).pdf
Date: 11/23/2015
File Size: 2.61 MB
Filename: RO_Web_TEW-827DRU(V1.0R).pdf
Date: 12/3/2015
File Size: 2.59 MB
Filename: NL_Web_TEW-827DRU(V1.0R).pdf
Date: 12/3/2015
File Size: 2.58 MB
Filename: HUG_Web_TEW-827DRU(V1.0R).pdf
Date: 11/23/2015
File Size: 2.62 MB

User's Guide

Filename: UG_TEW-827DRU(v1).pdf
Date: 11/8/2017
File Size: 3.73 MB

Product Images

JPEG Image
File Size: : 699.99 KB
Date: : 11/6/2015
JPEG Image
File Size: : 755.48 KB
Date: : 11/6/2015
JPEG Image
File Size: : 1.71 MB
Date: : 11/6/2015
JPEG Image
File Size: : 656.15 KB
Date: : 11/6/2015
JPEG Image
File Size: : 699.99 KB
Date: : 11/6/2015
JPEG Image
File Size: : 682.12 KB
Date: : 11/6/2015
JPEG Image
File Size: : 539.20 KB
Date: : 12/16/2015
ROHS compliant WEEE crossed-out bin symbol.
Standards
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3ab
  • IEEE 802.3az
  • IEEE 802.11a
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.11n (up to 800 Mbps)*
  • IEEE 802.11ac (up to 1733 Mbps)*
Hardware Interface
  • 4 x Gigabit LAN ports
  • 1 x Gigabit WAN port
  • 2 x USB 3.0 (Storage FTP, Samba, iTunes® Media Server, BitTorrent Client)
  • Power switch
  • WPS button
  • Reset button
  • WiFi on/off
  • LED on/off
  • LED indicators
Special Features
  • StreamBoost™ automatically identifies and classifies network traffic to maximize bandwidth and speed***
  • Multi-User MIMO for increased bandwidth efficiency and better user experience*
  • Multi-Language interface: English, French, Spanish, German, Russian
  • Pre-encrypted wireless network
  • IPv6 support
  • 1 guest network per band with option for internet access only
  • Up to 2 additional SSIDs per band
  • Dynamic DNS support for dyn.com, no-ip.com, and easydns.com
  • Samba/FTP server support
  • Implicit and Explicit Beamforming
Access Control
  • Wireless encryption up to WEP, WPA/WPA2-PSK, WPA/WPA2-RADIUS
  • Firewall: NAT, SPI, Virtual Server, Special Applications, Gaming, DMZ Host, allow/deny ping request from internet
  • ALG: PPTP/L2TP/IPsec VPN Passthrough, TFTP/FTP/RTSP/SIP/H.323 Passthrough
  • Parental (Access) Controls: MAC, URL, IP Filter
Quality of Service
  • WMM
  • StreamBoost™ Traffic Shaping***
Internet Connection Types
  • Dynamic IP (DHCP)
  • Static IP (Fixed)
  • PPPoE (Dynamic IP/Static IP)
  • PPTP (Dynamic IP/Static IP)
  • L2TP(Dynamic IP/Static IP)
  • Russia PPPoE (Dynamic IP/Static IP)
  • Russia PPTP (Dynamic IP/Static IP)
  • Russia L2TP (Dynamic IP/Static IP)
  • IPv6 (Static, Auto-configuration (SLAAC/DHCPv6), Link-Local, PPPoE, 6to4)
Management/Monitoring
  • Local/remote web based management
  • Upgrade firmware
  • Backup/restore configuration
  • Internal logging
  • Reboot
  • Restore to factory defaults
  • Ping test
Routing
  • Static
  • Dynamic (RIP v1/2)
Frequency
  • 2.412 – 2.472 GHz
  • 5.180 – 5.825 GHz
Modulation
  • 802.11b: CCK, DQPSK, DBPSK
  • 802.11a/g: OFDM with BPSK, QPSK and 16/64-QAM
  • 802.11n: BPSK, QPSK, 16-QAM, 64-QAM with OFDM
  • 802.11ac: OFDM with BPSK, QPSK and 16/64/256-QAM
Media Access Protocol
  • CSMA/CA with ACK
Antenna Gain
  • 2.4 GHz: 4 x 3 dBi (max.) detachable/external; 5 GHz: 4 x 5 dBi
Wireless Output Power (max output power without antenna gain)
  • 802.11a: FCC: 26 dBm (max.) / ETSI: 29 dBm (max.) / IC: 26 dBm (max.) @ 54 Mbps
  • 802.11b: FCC: 27 dBm (max.) / ETSI: 14 dBm (max.) / IC: 27 dBm (max.) @ 11 Mbps
  • 802.11g: FCC: 29 dBm (max.) / ETSI: 16 dBm (max.) / IC: 29 dBm (max.) @ 54 Mbps
  • 802.11n (2.4 GHz): FCC: 29 dBm (max.) / ETSI: 16 dBm (max.) / IC: 29 dBm (max.) @ 800 Mbps
  • 802.11n (5 GHz): FCC: 27 dBm (max.) / ETSI: 28 dBm (max.) / IC: 26 dBm (max.) @ 800 Mbps
  • 802.11ac: FCC: 27 dBm (max.) / ETSI: 28 dBm (max.) / IC: 26 dBm (max.) @ 1733 Mbps
Receiving Sensitivity
  • 802.11a: -68 dBm (typical) @ 54 Mbps
  • 802.11b: -83 dBm (typical) @ 11 Mbps
  • 802.11g: -70 dBm (typical) @ 54 Mbps
  • 802.11n (2.4 GHz): -64 dBm (typical) @ 800 Mbps
  • 802.11n (5 GHz): -68 dBm (typical) @ 800 Mbps
  • 802.11ac: -55 dBm (typical) @ 1733 Mbps
Wireless Channels
  • 2.4 GHz: FCC: 1-11; ETSI: 1-13
  • 5 GHz: FCC: 36, 40, 44, 48, 149, 153, 157, 161, 165; ETSI: 36, 40, 44, 48, (52, 56, 60, 64, 100, 104, 108, 112, 116, 132, 136, 140)**
Power
  • Input: 100 – 240 V AC, 50 – 60 Hz, 1 A
  • Output: 12V DC, 3 A external power adapter
  • Consumption: 31 Watts max.
Operating Temperature
  • 0 – 40 °C (32 – 104 °F)
Operating Humidity
  • Max. 95% non-condensing
Certifications
  • CE
  • FCC
Dimensions
  • 250 x 180 x 45 mm (9.8 x 7.1 x 1.8 in.)
Weight
  • 752 g (26.5 oz.)
Warranty
  • 90-day limited

PACKAGE CONTENTS

  • TEW-827DRU
  • Quick Installation Guide
  • CD-ROM (User's Guide)
  • 4 x Detachable high gain antennas
  • Network cable (1.5 m/5 ft.)
  • Power adapter (12V DC, 3 A)

*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network traffic, building materials and other conditions. For maximum performance of up to 1.733 Gbps use with a 1.733 Gbps 802.11ac wireless adapter. For maximum performance of up to 800 Mbps, use with an 800 Mbps 802.11n wireless adapter. Multi-User MIMO (MU-MIMO) requires the use of multiple MU-MIMO enabled wireless adapters.
** Due to regulatory requirements, the wireless channels specified cannot be statically assigned, but will be available within the available wireless channels when set to auto.
***Qualcomm® StreamBoost is a trademark of Qualcomm Atheros, Inc.

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
