Industrial 2.5G PoE+ Injector

TI-IG215 (Version v1.0R)

  • 1 x 2.5G PoE+ port (Data + PoE out)
  • 1 x 2.5G port (Data in)
  • 30W PoE power budget
  • Supports PoE (15.4W) and PoE+ (30W) devices
  • Uses IEEE 802.3af and IEEE 802.3at industry PoE standards for greater device interoperability
  • Network a PoE device located up to 100m (328 ft.) away
  • Fanless design eliminates operating noise and lowers energy consumption
  • Extreme operating temperature range - 40° — 75° C (-40° — 167° F)
  • Redundant power inputs with overload current protection
  • Includes DIN-Rail mount and wall mount
  • Power supply sold separately (model: TI-S15052)
  • NDAA / TAA compliant (U.S. and Canada only)
NDAA/TAA Compliant
Price: $77.99
Quantity:
Wishlist

TRENDnet’s Industrial 2.5G PoE+ Injector, model TI-IG215, allows users to add PoE+ power to a non-PoE 2.5G switch. Connect the 2.5G PoE+ injector to a non-PoE switch, and then run an Ethernet cable up to 100 meters (328 ft.) to network a PoE/PoE+ device. This multi-gig industrial PoE+ injector supplies up to 30W of power to a PoE device. The fanless design conveniently eliminates operating noise and lowers energy consumption. The 2.5G PoE+ injector is equipped with an IP50-rated metal enclosure, designed to withstand a high degree of vibration and shock, while operating within an extreme temperature range of -40° – 75° C (-40° – 167° F) for harsh industrial environments.

A TRENDnet TI-IG215 device with two Ethernet ports labeled DATA/PoE OUT and DATA IN. The DATA/PoE OUT port is highlighted with a green label indicating 2.5G PoE+, while the DATA IN port has a blue label indicating 2.5G. A lightning bolt symbol connects the DATA/PoE OUT port to a TRENDnet security camera, indicating a power output of 30 watts. The background is a gradient of blue shades.

PoE+

This multi-gig PoE+ injector supplies up to 30W of power to a PoE device.

A gauge with a black background and blue gradient outer area displays speeds measured in Mbps, marked from 0 to 10000. The needle points to 2500 Mbps, highlighted in red and yellow. Yellow text at the bottom indicates the unit of measurement.

2.5G Ports

Features a high-speed 2.5G port (data in) and a high-speed 2.5G PoE+ port (data + PoE out).

Four quadrants display icons representing different resistances. The top left shows a smartphone with lines indicating vibration resistance. The top right features a thermometer, suggesting temperature resistance. The bottom left presents a yellow lightning bolt for electrical resistance. The bottom right displays IP50, signifying a specific ingress protection level. The background is a blue gradient.

Industrial Design

IP50-rated metal enclosure with a high degree of vibration and shock resistance, and an extreme operating temperature range of -40° – 75° C (-40° – 167° F).

The TRENDnet TI-IG215 industrial gigabit PoE+ injector is mounted on a DIN rail, featuring LED indicators, a grounding point, 4-pin removable terminal blocks, one 2.5GBASE-T PoE+ port, and one 2.5GBASE-T port. Below it, a warehouse setting includes a PoE camera, a forklift, and stacked boxes. The injector powers the PoE camera, which is connected to a non-PoE switch and supported by a power supply, demonstrating its industrial application for device connectivity.

PoE+

This industrial 802.3at PoE injector supplies up to 30W of power to PoE (IEEE 802.3af) or PoE+ (IEEE 802.3at) devices

Industrial Design

Equipped with an IP50-rated metal enclosure, designed to withstand a high degree of vibration and shock, while operating within an extreme temperature range of -40° – 75° C (-40° – 167° F) for industrial environments

2.5G Ports

1 x 2.5G port (data in) and 1 x 2.5G PoE+ port (data + PoE out)

PoE Distance

Provides a PoE network connection up to 100m (328 ft.) away from the multi-gig industrial 802.3at PoE+ adapter

LED Indicators

LED indicators on the industrial PoE injector conveys power and PoE connectivity

Shock and Vibration Resistant

Rated for shock (EN 60068-2-27), freefall (EN 60068-2-32), and vibration (EN 60068-2-6)

Grounding Point

Grounding point protects equipment from external electrical surges

Fanless Design

Fanless design on the injector conveniently eliminates operating noise and lowers energy consumption

Housing Design

Compact and sturdy metal housing for installation flexibility

Standards
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3ab
  • IEEE 802.3af
  • IEEE 802.3at
  • IEEE 802.3bz
Device Interface
  • 1 x 2.5GBASE-T port (10M/100M/1G/2.5G)
  • 1 x 2.5GBASE-T PoE+ port (10M/100M/1G/2.5G)
  • 4-pin removable terminal block
  • LED indicators
Power
  • Input: 48 – 57V DC
  • Compatible power supply: TI-S15052 (sold separately)
  • Max. consumption: 4.3W @ 57V (with no PD connected)
PoE
  • PoE budget: 28 – 30W
  • Pins 1, 2, 3, and 6 for power (mode A)
Terminal Block
  • Redundant power inputs, 4 pin
  • Wire range: 0.34mm2 to 2.5mm2
  • Solid wire (AWG): 12-24/14-22
  • Stranded wire (AWG): 12-24/14-22
  • Torque: 5 lb. – In / 0.5Nm / 0.56 Nm
  • Wire strip length: 7-8mm
MTBF
  • 7,680,000 hours @ 25° C
Housing
  • IP50 metal case
  • DIN-Rail mount
  • Wall mount
  • Grounding point
  • Contact 6kV/Air 8kV ESD protection
  • 6kV RJ45 surge protection
Operating Temperature
  • - 40° — 75° C (-40° — 167° F)
Operating Humidity
  • Max. 95% non-condensing
Dimensions (L x W x H)
  • 60 x 58 x 26mm (2.36 x 2.28 x 1.02 in.)
Weight
  • 133g (4.7 oz.)
Certifications
  • CE
  • FCC
  • LVD
  • Shock (IEC 60068-2-27)
  • Freefall (IEC 60068-2-31)
  • Vibration (IEC 60068-2-6)
  • IEC 61000-4-2
  • IEC 61000-4-4
  • IEC 61000-4-5
Warranty
  • 3-year

PACKAGE CONTENTS
  • TI-IG215
  • Removable terminal block
  • DIN-Rail and wall mount kit

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
