AC1750 Dual Band Wireless Router

TEW-812DRU (Version v2.xR)

1750 Mbps total wireless: 1300 Mbps AC + 450 Mbps N bands
High speed USB 3.0 share port
Pre-encrypted for your convenience
Create an isolated guest network
One touch network connection with the WPS button
All Gigabit wired ports
High power amplifiers extend wireless coverage
Compatible with DD-WRT Open Source Firmware***

Designed to produce the ultimate wireless experience in a busy connected home, TRENDnet's AC1750 Dual Band Wireless Router, model TEW-812DRU, creates two concurrent wireless networks—a 1.3 Gigabit Wireless AC network and a 450 Mbps Wireless N network to connect common wireless devices. Use the high speed USB 3.0 port and Gigabit Ethernet ports to further expand your network.

Ease of Use

Easy Setup

Get up and running in minutes with the intuitive guided setup

One Touch Connection

Connect to the router at the touch of the Wi-Fi Protected Setup (WPS) button

USB 3.0 Share Port

Plug in a USB 3.0 flash or storage drive to share content at 5 Gbps USB 3.0 speeds

Encryption

Encrypted Wireless

For your convenience the router arrives pre-encrypted with its own unique password

Guest Network

Create a isolated network for guest internet access only

Parental Controls

Control access to specific websites

Performance

Next Generation Wireless AC

802.11ac provides uninterrupted HD video streaming in a busy connected home

Simultaneous Dual Band

High speed 1300 Mbps Wireless AC band + 450 Mbps Wireless N

Gigabit Ports

Gigabit ports extend high performance wired connections

Wireless Coverage

Whole home wireless coverage for average size homes

Backward Compatible

Compatible with legacy wireless devices

Targeted Beamforming

Increased real-time performance by directing stronger wireless signals to your specific location

Open Source

Compatible with DD-WRT open source firmware***

* Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and cover-age will vary depending on interference,network traffic, building materials and other conditions ** Printer Control Center utility installation required for each computer in order to access the printer ***The provided open source firmware has no affiliation with, nor was it produced by TRENDnet. Using this firmware requires advanced knowledge and experience with OpenSource code. TRENDnet does not provide support for this firmware. Use of this firmware voids the product warranty. This firmware may damage your product, use at your own risk.

Standards	IEEE 802.3 IEEE 802.3u IEEE 802.3ab IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n (up to 450 Mbps) IEEE 802.11ac (draft 2.0, up to 1.3 Gbps)
Hardware Interface	4 x Gigabit LAN ports 1 x Gigabit WAN port USB 3.0 (Storage FTP, Samba, Printing) Power switch (EU only) WPS button LED indicators
Encryption	Wireless encryption up to WPA2 Firewall: NAT, SPI Parental (Access) Controls: MAC, URL, IP Filter
System Requirements	Optional USB Printing utility: Windows: 8.1, 8, 7, Vista, XP, Mac OS X: 10.8, 10.7, 10.6, 10.5, 10.4
Special Features	QoS Management IPv6 support (6to4 and Native) WDS support Up to 3 multiple SSID per band 1 guest network per band with option for Internet access only DDNS support for dyn.com & no-ip.com Samba/FTP server support Multi-Language interface: English, French, Spanish, German, Russian
Open Source	Compatible with DD-WRT Firmware
Antenna Gain	2.4 GHz: 6 dBi (Max) internal/5 GHz: 6 dBi (Max) internal
Wireless Output Power/Receiving Sensitivity	802.11a: FCC: 22 dBm, CE: 18 dBm (Max)/-68 dBm (typical) @ 54 Mbps 802.11b: 19 dBm (Max) /-84 dBm (typical) @ 11 Mbps 802.11g: 18 dBm (Max) /-72 dBm (typical) @ 54 Mbps 802.11n: FCC: 18 dBm (Max) /-68 dBm (typical) @ 450 Mbps 2.4 GHz 802.11n: FCC: 22 dBm, CE: 18 dBm (Max)/-68 dBm (typical) @ 450 Mbps 5 GHz 802.11ac: FCC: 23 dBm, CE: 19 dBm (Max)/-55 dBm (typical) @ 1.3 Gbps
Power	Input: 100 - 240 V, 50 – 60 Hz, 0.8 A Output: 12 V DC, 2 A Consumption: 21 Watts (Max)
Operating Temperature	0 - 40°C (32 - 104°F)
Operating Humidity	Max 90% non-condensing
Certifications	CE FCC
Dimensions/Weight	48 x 155 x 180 mm (1.8 x 6.1 x 7.1 in) 395 g (14 oz.)
Warranty	3 year limited

PACKAGE CONTENTS

TEW-812DRU
Multi-Language Quick Installation Guide
CD-ROM (Utility & User's Guide)
Network cable (1.5 m/5 ft.)
Power adapter (12 V, 2 A)

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
