AC600 Dual Band Wireless USB Adapter

TEW-804UB (Version v1.0R)

Upgrade your computer to 433 Mbps Wireless AC
Connect to a Wireless N network at up to 150 Mbps
Quick intuitive setup
Powered by the computer's USB port
One touch network connection with the WPS button
Windows® and Mac® compatible

DISCONTINUED PRODUCT

The TEW-804UB (Version v1.0R) has been discontinued. It has been replaced by the TEW-809UB (Version V1). For a list of discontinued products, click here.

TRENDnet's AC600 Dual Band Wireless USB Adapter, model TEW-804UB, connects a Windows® or Mac® computer to a revolutionary Wireless AC network. Connect to a Wireless AC network at up to 433 Mbps or to a Wireless N network at up to 150 Mbps. This high performance adapter comes in a compact form factor.

Ease of Use

Easy Setup

Get up and running in minutes with the intuitive guided setup

One Touch Connection

Connect to a wireless network at the touch of the Wi-Fi Protected Setup (WPS) button

Encryption

Encrypted Wireless

Supports the latest encryptions standards (up to WPA2)

Performance

Next Generation Wireless AC

802.11ac provides HD video streaming in a busy connected home

Dual Band

High speed 433 Mbps Wireless AC or 150 Mbps Wireless N network connection

Backward Compatible

Compatible with older wireless devices

Operating Systems

Compatible with Windows® and Mac® operating systems

*For maximum performance of up to 433 Mbps use with a 433 Mbps 802.11ac wireless router or access point**Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network traffic, building materials and other conditions

Standards	IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n (2.4 + 5 GHz: up to 150 Mbps) IEEE 802.11ac (draft 2.0, up to 433 Mbps)
Hardware Interface	USB 2.0 WPS Button/LED indicator
Encryption	Wireless encryption up to WPA2
Compatibility	Windows® 8, 7, Vista, XP Mac OS® 10.4-10.10
Special Features	Compact form factor High-speed 802.11ac connectivity
Power	Consumption: Max. 224 mA
Operating Temperature	0 - 40°C (32 - 104°F)
Operating Humidity	Max. 95% non-condensing
Certifications	CE FCC
Dimensions	38 x 19 x 8 mm (1.5 x 0.75 x 0.31 in.)
Weight	5 g (0.18 oz.)
Warranty	3-year limited

PACKAGE CONTENTS

TEW-804UB
Multi-Language Quick Installation Guide
CD-ROM (Utility & Drivers)

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.

Not Available in
