TRENDnet's 8-Port Fast Ethernet PoE+ Switch, model TPE-T80H, reduces equipment and installation costs by delivering data and power over existing Ethernet cables. This unmanaged desktop PoE switch offers eight fast ethernet PoE+ ports which supply up to 30W of power per port for devices such as high power wireless access points, IP Cameras, and VoIP telephony systems. It supports both PoE (802.3af) and PoE+ (802.3at) devices with a 110W PoE budget. This rack mountable switch features a fanless design that eliminates operating noise.

PoE+ Power
A 110W PoE power budget supplies up to eight Power over Ethernet devices.

Fast Ethernet
Eight Fast Ethernet ports provides a 1.6Gbps switching capacity to support edge network installations.

Fanless
Fanless design eliminates operating noise.
Standards | - IEEE 802.3
- IEEE 802.3u
- IEEE 802.3x
- IEEE 802.3ab
- IEEE 802.3af
- IEEE 802.3at
- IEEE 802.3az
- IEEE 802.1Q
|
Device Interface | - 8 x Fast Ethernet PoE/PoE+ ports
- LED indicators
|
Data Transfer Rate | - Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
- Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
|
Performance | - Packet Buffer: 56KB
- Switch Fabric: 1.6Gbps
- MAC Address Table: 1K entries
- Forwarding Rate: 1.19Mpps (64-byte packet size)
|
Power | - Input: 110-240V AC, 50/60 Hz, internal power supply
- Max. Consumption: 130W
|
PoE | - PoE budget: 110W
- Pin 1, 2 for power+ and pin 3, 6 for power- (mode A)
|
Fan/Acoustics | |
Operating Temperature | - 0° – 40° C (32° - 104° F)
|
Operating Humidity | |
Dimensions | - 265.1 x 183.7 x 44mm (10.4 x 7.2 x 1.7 in.)
|
Weight | |
Certifications | |
Warranty | |
PACKAGE CONTENTS |
- TPE-T80H
- Quick Installation Guide
- Rackmount kit
- Power cord
|
All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
