TRENDnet’s Indoor 2 MP 1080p WDR Mini Pan / Tilt PoE IR Network Camera, model TV-IP410PI, provides day and night surveillance with a night vision range of up to 10 meters (32.8 ft.) This mini pan / tilt network camera features adjustable wide dynamic range (WDR) image balancing that enhances image quality and clarity when exposed to high contrast lighting environments. Record 1080p video (1920 x 1080) at 30 fps in a space saving H.264+ compression format. Manage up to 32 TRENDnet cameras with included complimentary software and mobile apps.
Pan / Tilt
Motorized 180° pan and 75° tilt offers greater visibility over the environment and can be remotely controlled over the internet.
Power over Ethernet (PoE)
PoE offers cost savings, and the flexibility to install this mini pan / tilt camera in the desired location.
Wide Dynamic Range (WDR)
Adjustable wide dynamic range (WDR) image balancing that enhances image quality and clarity when exposed to high contrast lighting environments.
Record 1080p (1920 x 1080) HD video at 30 fps in space saving H.264+ compression format
Night vision up to 10 meters (32.8 ft.)
Dynamic IR LED adjustment optimizes night visibility by varying intensity based on object distance
Save installation costs with Power over Ethernet (PoE)
Record video to a network storage device or to a micro SD card (up to 128 GB, not included).
Advanced in-camera archived video review functionality
Create custom motion detection zones to record video and send email notifications when a zone is triggered.
Create custom tamper detection zones to send an email notification when the camera view has been obstructed.
Digital Wide Dynamic Range (D-WDR)
Adjustable D-WDR setting improves image quality and clarity when a camera is exposed to high contrast lighting environments by enhancing the dark areas of the image to make them more visible.
Define custom schedules using continuous (24/7) and / or event based recording modes.
ONVIF / PSIA
ONVIF Profile S, Profile G and PSIA compliant
Complimentary pro-grade software to manage up to 32 TRENDnet cameras
Live video to a mobile device with free iOS®and Android™apps
Focal Length: 2.8 @ F2.0
Sensor: 1/2.8” CMOS sensor
DNR: 3D DNR
WDR: 120 dB
Pan: -90 ~ 90˚
Tilt: 0 ~ 75˚
IR off: 0.01 lux
IR on: 0 lux
IR wavelength : 850nm
H.264/H.264+: 1920 x 1080 up to 25 fps
H.264/MJPEG: 640 x 360 up to 30 fps
10/100 Mbps PoE port
Micro SD card slot
Supports Micro SD/SDHC/SDXC
Up to 128GB
IPv4, IPv6, UDP, TCP / IP, ONVIF, SPIA
DHCP, NTP, DDNS, SMTP, FTP, LLTD
SNMP v1-v3, QoS / DSCP, IEEE 802.1X
NFS, SMB/CIFS, Bonjour
UPnP, RTSP, RTP
ONVIF Profile S, Profile G, PSIA
120 x 87 mm (4.7 x 3.4 in.)
500 g (1 lb.)
-10 – 40 °C (-14 – 104 °F)
Max. 95% non-condensing
Consumption: 5W avg. (7W IR on, 9W P/T on)
Power (Power adapter not included)
Input: 100 - 240 V AC , 50/60 Hz, 1 A
Output: 12 V DC, 1 A external power adapter (for non-PoE installations)
Multi-language support: English, French, German, Spanish and Portuguese
IP address filter
QoS traffic prioritization
Time, date, and text overlay
Image settings: brightness, contrast, hue, sharpness, Denoise 3D, Shutter time, sense-up, Saturation, AGC (automatic gain control), flip, day/night mode, white balance
WDR enhances video quality in high contrast daytime lighting
2D Digital Noise Reduction enhances night vision quality
Recording: to computer, NAS, SAMBA, or through software
Video Recording: scheduled, motion detection, sound detection, and tamper detection
Motion detection: define up to three motion detection areas and motion sensitivity
Privacy masks: define custom privacy mask up to 3 areas
Tamper detection function: email notification, FTP, SD card, or Samba server if the viewing field darkens suddenly
Network disconnection fallback: set to automatically save video to Micro SD card (sold separately) if connection to network is broken
Snapshot: real time snapshot, sound detection, and motion detection
Supported dynamic DNS services: dyn.com, no-ip.com, and iptecno.com
Management setting: maximum 21 user accounts
Supports remote management
Compatible browsers: Chrome™ or Firefox® (live view resolution up to 640 x 360), Internet Explorer® or Safari® (live view resolution up to 1920 x 1080)
TRENDnetVIEW EVO Software
Supports up to 32 TRENDnet cameras
Multiple language support
Set recording options (motion detection, schedule, event trigger)
Search and playback
Custom viewing modes and options
Compatibility: Windows® 10, 8.1, Windows Server® 2012, 2008
TRENDnet IPVIEW App
Free iOS® and Android™ apps
View live camera video on a mobile device
Quick Installation Guide
CD-ROM (Utility, Software, & User’s Guide)
Camera mounting hardware
All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
