10-Port 2.5G Switch with 10G SFP+ Ports

TEG-S5091 (Version V2)

  • 8 x 2.5G RJ45 ports
  • 2 x 10G SFP+ ports
  • Compatible with existing Cat5e or better cabling
  • Backward compatible SFP speeds of 1000Mbps
  • Fanless design eliminates noise
  • Wall mountable for installation flexibility
  • 80Gbps switching capacity
  • IEEE 802.3bz (2.5G) and IEEE 802.3ae (10G SFP+) compliant
  • NDAA / TAA compliant (U.S. and Canada only)
  • Lifetime Warranty*
NDAA/TAA Compliant
Coming Soon

Expand your network’s bandwidth and reduce digital bottlenecks with TRENDnet’s 10-Port 2.5G Switch with 10G SFP+ Ports, model TEG-S5091. This 2.5G/10G switch comes equipped with 2.5GBASE-T RJ45 ports that provide speeds capable of up to 2.5Gbps over your existing Cat5e or better cabling, and 10G SFP+ ports for ultra-fast, long-distance fiber networking. This 2.5G switch features a durable metal enclosure and can be mounted to the wall for installation flexibility. The fanless design lowers energy consumption and eliminates operating noise. TRENDnet’s reliable 2.5G/10G switch is a cost-effective solution to increase your network’s throughput.

Speedometer-style gauge with black face and white, blue, and red markings, displaying internet speed in Mbps. Needle points to 2500 Mbps, highlighted in red. Gauge scale ranges from 0 to 10000 Mbps. Background is a light blue gradient.

2.5G Ports

Equipped with 2.5GBASE-T RJ45 ports that provide ultra-fast speeds capable of up to 2.5Gbps over existing Cat5e or better cabling.

TRENDnet TEG-S5091 Multi-Gigabit Switch with eight Ethernet ports labeled 1 through 8 and two 10G SFP+ ports labeled 9 and 10. Inset highlights the 10G SFP+ ports with 10G label. Front panel includes power indicator labeled PWR and 2.5G marking. Set against a blue background.

10G SFP+ Ports

Dedicated 10G SFP+ ports for ultra-fast network connections provides a cost-effective solution in adding 10G link capability to an SMB network

TRENDnet TEG-S5091 Multi-Gigabit Switch with eight Ethernet ports labeled 1 through 8 and two SFP+ ports labeled 9 and 10. Power indicator labeled PWR is lit. A graphic of a fan with a diagonal line above the switch signifies fanless silent operation. Set against a blue background

Fanless

The fanless design of the 2.5G switch lowers energy consumption costs and eliminates operating noise.

TRENDnet TEG-S5091 Multi-Gigabit Switch shown at top with labeled ports including eight 2.5G RJ45, two 10G SFP+, LED indicator, and DC 12V power input. Lower section displays a home network layout with connected devices including 2.5G PCIe adapter, WiFi 6 router, WiFi 6 access point, 2.5G PoE+ injector, and 2.5G USB adapter. Switch is located in the living room, set against a blue background.

Easy Installation

No configuration needed, simply connect network devices to the 2.5G/10G switch

2.5G Ports

Equipped with 2.5GBASE-T RJ45 ports, the 2.5G Ethernet switch provides ultra-fast speeds capable of up to 2.5Gbps over existing Cat5e or better cabling

10G SFP+ Ports

Dedicated 10G ports for ultra-fast network connections provides a cost-effective solution in adding 10G link capability to an SMB network

Switching Capacity

80Gbps switching capacity

Fanless

Fanless design on the 2.5Gb switch lowers energy consumption and eliminates operating noise

Housing Design

Sturdy metal housing

Wall Mountable

Features a convenient wall mountable design for greater installation flexibility

Jumbo Frame

Sends larger packets, or Jumbo Frames (up to 10KB) for increased performance

LED Indicators

LED indicators on this 2.5G/10G switch conveys port status

Standards
  • IEEE 802.3x
  • IEEE 802.3z
  • IEEE 802.3u
  • IEEE 802.3ab
  • IEEE 802.3ae
  • IEEE 802.3az
  • IEEE 802.3bz
Device Interface
  • 8 x 2.5G RJ45 ports (100Mbps/1Gbps/2.5Gbps)
  • 2 x 10G SFP+ ports (1Gbps/10Gbps)
  • LED indicators
Performance
  • Switching Capacity: 80Gbps
  • RAM Buffer: 1MB
  • MAC Address Table: 16K entries
  • Forwarding Rate: 59.52Mpps (64-byte packet size)
  • Jumbo Frames: 10KB
Special Features
  • Wall mountable
Power
  • Input: 90 – 264V AC, 50/60 Hz, 0.2A
  • Output: 12V DC, 1A external power adapter
  • Max. Consumption: 10.2W
Fan/Acoustics
  • Fanless design
MTBF
  • 793,494 hours @ 25° C
Operating Temperature
  • 0° – 40° C (32° – 104° F)
Operating Humidity
  • Max. 90% non-condensing
Dimensions (L x W x H)
  • 193 x 84 x 26mm (7.6 x 3.3 x 1.02 in.)
Weight
  • 426g (15 oz.)
Certifications
  • FCC
  • CE
  • LVD
Warranty

PACKAGE CONTENTS
  • TEG-S5091
  • Power adapter (12V DC, 1A)

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
