2-Pack 10G RJ45 Copper SFP+ Module

TEG-10GBRJ/2 (Version V1)

  • Connect devices up to 30m (98ft.) over Cat6A cabling (or better) at 10G speeds
  • Compliant with IEEE 802.3an 10G Ethernet
  • Backwards compatible with IEEE 802.3bz multi-gigabit (2.5G / 5G) speeds
  • Shielded RJ45 copper interface
  • Low Electromagnetic Interference (EMI) design
  • Digital Diagnostics Monitoring (DDM) support
  • Small Form-Factor Pluggable (SFP+) and Multi-Source Agreement (MSA) compliant
  • Hot-Pluggable
  • Low power consumption
  • NDAA / TAA compliant (U.S. and Canada only)
  • Lifetime Warranty*
NDAA/TAA Compliant

TRENDnet’s 2-Pack 10G RJ45 Copper SFP+ Module, model TEG-10GBRJ/2, converts standard SFP+ ports into an RJ45 multi-gigabit port for additional high-speed copper connectivity. These 10G copper SFP+ modules work with standard SFP+ ports commonly found in network switches and fiber media converters. Save on equipment costs by repurposing a switch’s unused SFP+ ports for reliable copper connectivity with TRENDnet’s 10G copper SFP+ modules.

A network switch with several ports is shown, with an arrow pointing to a specific port. Below it, a transceiver module is connected to a cable, demonstrating the connection setup. The background features a gradient of blue tones.

RJ45 Copper SFP+

Take advantage of unused SFP+ ports and repurpose them for RJ45 copper multi-gigabit connectivity.

Two location markers are connected by a dotted line across a gradient blue background, indicating a distance of 30 meters or 98 feet between them.

10G Speeds

These SFP+ modules span distances up to 30m (98 ft.) and supports up to 10Gbps speeds.

A TRENDnet TEG-10GBRJ module is positioned next to a network switch with an arrow indicating the correct port for insertion. The highlighted port stands out from the adjacent four, emphasizing proper installation. The background features a smooth blue gradient.

Compatibility

Compatible with an MSA compliant SFP+ port and multi-gigabit RJ45 copper connections.

The TRENDnet TEG-10GBRJ/2 is a 10G RJ45 Copper SFP+ Module labeled as SFP+ MSA Compliant, featuring an RJ45 connector. Below is an illustration showing an arrow indicating the connection from one switch to another via the SFP+ slot.

Interface

Converts an SFP+ port to a 10Gbps RJ45 port

SFP+

Take advantage of unused SFP+ ports and repurpose them for RJ45 copper multi-gigabit connectivity

10G Speeds

These SFP+ modules span distances up to 30m (98 ft.) and supports up to 10Gbps speeds

Compatibility

Compatible with an MSA compliant SFP+ port and multi-gigabit RJ45 copper connections

Hot-Pluggable

Hot-pluggable 10G copper SFP+ compatible with an MSA compliant SFP+ port

Operating Temperature

Features an operating temperature range of 0°– 65° C (0° – 149° F)

Standards
  • IEEE 802.3
  • IEEE 802.3az
  • IEEE 802.3an
  • IEEE 802.3ab
  • IEEE 802.3bz
Device Interface
  • SFP+ MSA compliant
  • RJ45 connector
Data Transfer Rate
  • Up to 10Gbps
Distance
  • 10Gbps up to 30m (98 ft.) with Cat6A/7
  • 2.5G/5Gbps up to 50m (164 ft.) with Cat5e
  • 1Gbps up to 100m (328 ft.) with Cat5e
Special Features
  • Hot pluggable
  • Metal enclosure
  • DDM support
Power (per unit)
  • Max. consumption: 3W
Operating Temperature
  • 0° – 65° C (32° – 149° F)
Operating Humidity
  • Max. 95% non-condensing
Dimensions (per unit)
  • 68.8 x 13.8 x 13.4mm (2.7 x 0.53 x 0.52 in.)
Weight (per unit)
  • 24g (0.8 oz.)
Certifications
  • CE
  • FCC
Warranty

PACKAGE CONTENTS
  • 2 x TEG-10GBRJ

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
