TRENDnet’s 8-Port Industrial Fast Ethernet DIN-Rail Mini Switch, model TI-ELC80, is a reliable and rugged networking solution designed for use in both extreme and demanding environments. This industrial Fast Ethernet DIN-Rail mini switch features a rugged IP30 rated metal enclosure, and is designed to withstand a high degree of vibration and shock, while operating in both high and low temperatures for industrial environments within -40° – 75° C (-40° – 167° F). The hardened industrial switch features five copper Ethernet ports for stable device connections. The mini-sized housing is designed to fit into most compact installation areas.
Fast Ethernet Ports
Up to 200Mbps full-duplex per port and total switching capacity of 1Gbps.
Industrial Hardened Design
Equipped with a rugged IP30 rated housing, designed to withstand a high degree of vibration and shock, and operate within an extreme temperature range of -40° – 75° C (-40° – 167° F).
Mini Design
With a compact metal housing design, this mini network switch is well-suited for installations into most environments. Its fanless design is perfect for quiet environments that require silent operation.
Standards | - IEEE 802.3
- IEEE 802.3u
- IEEE 802.3x
|
Device Interface | - 8 x 10/100Mbps ports
- 3-pin removable terminal block
- LED indicators
|
Data Transfer Rate | - Ethernet: 10Mbps (half-duplex), 20Mbps (full-duplex)
- Fast Ethernet: 100Mbps (half-duplex), 200Mbps (full-duplex)
|
Performance | - Data RAM Buffer: 56KB
- Switching Fabric: 1Gbps
- MAC Address Table: 1K entries
- Forwarding rate: 1.19Mpps (64-byte packet size)
|
Special Features | - Hardened components rated for extreme temperatures
- Auto-Negotiation
- Auto store and forward architecture
- Automatic address learning and address aging
- ESD 6KV protection
|
Power | - Input: 9.6 – 60V DC
- Compatible power supply: TI-M6024 (sold separately)
- Max. consumption: 1.68W
|
Terminal Block | - 3-pin terminal block
- Wire range: 1.5mm^2
- Solid wire (AWG): 16-28
- Stranded wire (AWG): 16-28
- Torque: 3 lb. – In / 0.2Nm / 0.56Nm
- Wire strip length: 6-7mm
|
MTBF | |
Housing | - IP30 metal case
- DIN-Rail mount
- Wall mount
- Grounding point
- ESD 6KV protection
|
Operating Temperature | - - 40° - 75° C (-40° - 167° F)
|
Operating Humidity | |
Dimensions | - 100.5 x 81.5 x 40mm (3.95 x 3.2 x 1.6 in.)
|
Weight | |
Certifications | - CE
- FCC
- LVD
- Shock (EN 60068-2-27)
- Freefall (EN 60068-2-31)
- Vibration (EN 60068-2-6)
- ESD 6KV
- EFT 2KV
- Surge 2KV
|
Warranty | |
PACKAGE CONTENTS |
- TI-ELC80
- Quick Installation Guide
- Removable terminal block
- DIN-Rail and wall mount kit
|
All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
