Products » Multi-Gigabit » Switches » TEG-S380

8-Port Unmanaged 2.5G Switch

TEG-S380 (Version v1.xR)

8 x 2.5GBASE-T ports
IEEE 802.3bz (2.5G) compliant
Backwards compatible with 10/100/1000Mbps devices
40Gbps switching capacity
Fanless design eliminates noise
Wall mountable for installation flexibility
NDAA / TAA compliant (U.S. and Canada only)

Expand your network’s bandwidth and reduce digital bottlenecks with TRENDnet’s Unmanaged 2.5G Switches. These 2.5G network switches come equipped with 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over your existing Cat5e or better cabling. Each high-speed 2.5G switch features a durable metal enclosure and can be mounted to the wall for setup flexibility. The fanless design lowers energy consumption and eliminates distracting operating noise. TRENDnet’s reliable 2.5G switches are cost-effective solutions to increase your network’s throughput.

2.5G Ports

Equipped with 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over existing Cat5e or better cabling.

Wall Mountable

The 2.5G switches feature metal housing with a convenient wall mountable design for greater installation flexibility.

Fanless

The fanless design of the 2.5G switches lowers energy consumption costs and eliminates operating noise.

Easy Installation

No configuration needed, simply connect network devices to the 2.5G Ethernet switch

2.5G Ports

Equipped with 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over existing Cat5e or better cabling

Fanless

Fanless design lowers energy consumption and eliminates operating noise

Housing Design

Sturdy metal housing

Wall Mountable

Features a convenient wall mountable design for greater installation flexibility

Jumbo Frame

Sends larger packets, or Jumbo Frames (up to 12KB) for increased performance

LED Indicators

LED indicators on this 2.5G switch conveys port status

Standards	IEEE 802.3x IEEE 802.3z IEEE 802.3ab IEEE 802.3az IEEE 802.3bz
Device Interface	8 x 2.5GBASE-T ports (1Gbps/2.5Gbps) LED indicators
Data Transfer Rate	Gigabit: 2000Mbps (full duplex) 2.5 Gigabit: 5Gbps (full duplex)
Performance	Switching Capacity: 40Gbps RAM Buffer: 1.5MB MAC Address Table: 16K entries Forwarding Rate: 29.76Mpps (64-byte packet size) Jumbo Frames: 12KB
Special Features	Wall-Mountable
Power	Input: 100 – 240V AC, 50/60 Hz, 0.6A Output: 12V DC, 1.5A Max. Consumption: 12.4W
Fan/Acoustics	Fanless design
MTBF	1,401,356 hours
Operating Temperature	0° – 40° C (32° – 104° F)
Operating Humidity	Max. 90% non-condensing
Dimensions (L x W x H)	240 x 103 x 26mm (9.4 x 4.0 x 1.02 in.)
Weight	600g (1.32 lbs.)
Certifications	FCC CE
Warranty	3 year

PACKAGE CONTENTS

TEG-S380
Quick Installation Guide
Power adapter (12V DC, 1.5A)

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
