SFP+ Single Mode LC Module (40km)

TEG-10GBS40 (Version v3.0R)

Transmission distance of up to 40km (24.9 mi.)
Duplex LC optical interface
Supports data rates of up to 10.31Gbps
Supports 1550nm single mode network transmissions
Low Electromagnetic Interference (EMI) design
Compliant with IEEE 802.3ae 10 Gigabit Ethernet
Digital Diagnostics Monitoring (DDM) support
Small Form-Factor Pluggable (SFP+) and Multi-Source Agreement (MSA) compliant
Low power consumption
NDAA / TAA compliant (U.S. and Canada only)
Lifetime Warranty*

TRENDnet’s SFP+ Single Mode LC Modules are compatible with standard SFP+ slots found on network switches and fiber media converters. The single mode 10G SFP+ transceiver is equipped with a duplex LC fiber connection interface, and supports high-speed data rates up to 10.31Gbps. All TRENDnet 10G SFP+ fiber modules support connections for reliable, long-distance network applications.

Two identical factory buildings with multiple windows and three smokestacks each are connected by a dotted line, indicating a relationship between them. The background features a gradient transitioning from light blue at the top to dark blue at the bottom.

Fiber Applications

Long distance fiber networking for manufacturing, business parks, and school campus applications.

Two location markers are connected by a dotted line on a gradient blue background with a labeled distance of 40km 24.9 mi between them.

Fiber Mode/Distance

Single mode 10G SFP+ transceiver spans distances up to 40km (24.9 mi.) at 10G speeds.

A TRENDnet TEG-10GBS40 SFP+ module is placed below a diagram of a network switch, with an arrow pointing to the SFP port where the module should be inserted. The background consists of blue gradient shades.

Compatibility

Hot-pluggable SFP+ transceiver works with an MSA compliant 10G SFP+ slot.

A TRENDnet TEG-10GBS40 SFP+ transceiver module is shown with labels indicating that it is SFP+ MSA compliant and features an LC duplex connector supporting 1Gbps and 10Gbps. Below, a diagram illustrates the module's connection to a switch and a media converter, using arrows and lines to depict the data flow between the devices.

Fiber Distance

Ideal for reliable, long-range networking distances

Fiber Interface

Single mode fiber SFP+ transceiver supports LC-type duplex connector

Fiber Wavelength

Single mode fiber SFP+ module compatible with 1550nm transmissions

Data Rate

10GB SFP supports data rates up to 10.31Gbps

Hot-Pluggable SFP

Hot-pluggable 10G SFP+ transceiver compatible with an MSA compliant SFP slot

Standards	IEEE 802.3 IEEE 802.3u IEEE 802.3z IEEE 802.3ae 10GBASE-ER
Device Interface	SFP+ MSA Compliant LC duplex connector (1Gbps / 10Gbps)
Data Transfer Rate	Up to 10.3Gbps
Wavelength	1550nm
Optical Output Power	-2 ~ 2 dBm
Distance	40km (24.9 mi.)
Special Features	DDM support
Sensitivity	-16 dBm
Power	Max.consumption: 0.8W
Operating Temperature	0° – 70° C (32° – 158° F)
Operating Humidity	Max. 95% non-condensing
Dimensions	58 x 13.4 x 12.6mm (2.2 x 0.5 x 0.5 in.)
Weight	18g (0.6 oz.)
Certifications	CE FCC
Warranty	Lifetime Warranty*

PACKAGE CONTENTS

TEG-10GBS40

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
