N300 Wireless Home Router

TEW-652BRP (Version V1.0R)

  • 12x the speed and 4x the coverage of wireless g
  • Stream video, download files, talk online and play games all at the same time
  • Advanced wireless encryption and a firewall provides robust security

The N300 Wireless Home Router delivers the highest level of security with 12x the speed and 4x the range of wireless g products. Quickly install the router and use it with TRENDnet wireless n adapters to receive the full benefits of wireless n speed and coverage.

The latest in wireless encryption and a secure firewall provide the ultimate in wired and wireless security. Advanced Multiple Input Multiple Output (MIMO) antenna technology delivers expansive coverage and eliminates dead spots. A quick and intuitive installation process, one touch wireless connection using Wi-Fi Protected Setup and advanced management capabilities make this product well suited for your most demanding home networking needs.

  • Wi-Fi compliant with IEEE 802.11n and IEEE 802.11b/g standards
  • 4 x 10/100Mbps Auto-MDIX LAN port and 1 x 10/100Mbps WAN port (Internet)
  • Supports Cable/DSL modems with Dynamic IP, Static IP, PPPoE, PPTP, L2TP & BigPond connection types
  • High-speed up to 300Mbps data rate using IEEE 802.11n connection
  • 2 external antennas support high speed performance and great coverage with MIMO technology
  • Firewall features Network Address Translation (NAT), and Stateful Packet Inspection (SPI) protects against DoS attacks
  • Support Wi-Fi Protected Setup (WPS) for easy connection
  • Universal Plug and Play (UPnP) and Application Level Gateway support for internet applications such as email, FTP, gaming, remote desktop, Net Meeting, telnet and more
  • Provides additional security of enable/disable wireless SSID, Internet Access Control (MAC Address, Domain & IP Filtering)
  • Easy management via web browser and remote management
  • Supports 64/128-bit WEP, WPA/WPA2 and WPA-PSK/WPA2-PSK
  • Wi-Fi Multimedia (WMM) Quality of Service (QoS) supported
  • Multiple VPN Pass-through sessions for IPSec, PPTP and L2TP
  • Works with Windows 95/98/NT/2000/XP/2003 Server/Vista, Linux and Mac OS
  • Coverage up to 100 meters (330ft.) indoor;(depends on the environment)
  • Coverage up to 300 meters (980ft.) outdoor;(depends on the environment)
  • 3-year limited warranty
Hardware
Standards Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX)
Wireless: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n (draft 2.0)
WAN 1 x 10/100Mbps Auto-MDIX port (internet)
LAN 4 x 10/100Mbps Auto-MDIX ports
WPS Button Enable Wi-Fi Protected Setup function
Connection Type Dynamic IP, Static (Fixed) IP, PPPoE, PPTP, L2TP, BigPond
UPnP UPnP IGD 1.0 compliant
DMZ DMZ host & Virtual Servers
DNS Static or WAN assigned DNS servers; 3 verified services for DDNS
Internet Access Control MAC Address Filter, Domain/URL Filter, Protocol/IP Filter
Logging 5 types of event logging; email report
LED Indicator Power, LAN1~LAN4, WAN, WLAN
Power Adapter 5V DC, 2.5A external power adapter
Power Consumption 7watts (max.)
Dimension (L x W x H) 150 x 110 x 30 mm (5.9 x 4.3 x 1.1 inches)
Weight 245g (8.6 oz)
Temperature Operation: 0°~ 40°C (32°F~ 104°F); Storage: -10°~ 70°C (14°F~158 °F)
Humidity Max. 90% (non-condensing)
Certifications CE, FCC
Wireless
Frequency 2412~2484MHz ISM band
Antenna 2 x 2dBi detachable dipole antennas
Media Access Protocol CSMA/CA with ACK
Data Rate 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps
802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps
802.11n: up to 300Mbps
Security WEP(HEX/ASCII): 64/128-bit WPA(AES/TKIP): WPA/WPA2, WPA-PSK/WPA2-PSK
Enable/Disable broadcast SSID
Output Power 802.11b: 17dBm (typical)
802.11g: 13dBm (typical) 802.11n: 13dBm (typical)
Receiving Sensitivity 802.11b: -85dBm (typical) @ 11Mpbs
802.11g: -68dBm (typical) @ 54Mbps
802.11n: -62dBm (typical) @ 300Mbps
Channels 1~ 11 (FCC), 1~13 (ETSI)
PACKAGE CONTENTS
  • TEW-652BRP
  • Multi-Language Quick Installation Guide
  • CD-ROM (User's Guide)
  • Power adapter (5V DC, 2.5A)
  • Cat. 5 Ethernet cable (1.5m/5ft.)

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
