TEW-AI86D Indoor Directional Antenna provides more power and greater range for your wireless network. As an optional antenna for your IEEE 802.11b/g 2.4GHz or 802.11a 5GHz wireless network equipment, TEW-AI86D will significantly improve signal strength and quality. TEW-AI86D will work with any brand of device with reverse SMA male connector!!
* This dBi gain does not factor cable loss. Performance estimations are for typical use; range will vary with site conditions.
Compatible with 2.4GHz 802.11b/g or 5GHz 802.11a wireless devices.
Works with any brand of wireless devices with reverse SMA male connector
Serves as an indoor directional relocation antenna
Enhances wireless coverage and improve signal transmission and reception
Adjustable antenna face can tile up to 180° and rotate up to 360° angle for optimal performance.
No configuration or installation software required
3-year limited warranty
802.11a: 4.9 ~5.875GHz 802.11b/g: 2.4 ~ 2.5GHz
802.11a: 8dBi 802.11b/g: 6dBi
802.11a: 50° 802.11b/g:75°
802.11a: 60° 802.11b/g:70°
Reverse SMA Female
128 x 85 x 15mm (5.04 x 3.35 x 0.59in.)
-10°C ~ 55°C (14°F ~ 131°F)
95% at 25°C
Multi-Language User's Guide
All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
