2-Port 10/100Mbps Switch Fiber Hub

TE100-S22FX   (Version 1.0)

  • This 2 port auto-sensing hub easily link 10Base-T, 100Base-TX, and 100Base-FX network group segments
  • The TE100-S22FX is designed for plug and play installation, and is equipped with LED's for easy troubleshooting
  • Enjoy a 5-year user warranty

DISCONTINUED PRODUCT

The TE100-S22FX (Version 1.0) has been discontinued. For a list of discontinued products, click here.
Hardware
Protocol:
  • CSMA/CD
Speed:
  • 10Mbps (half duplex) / 20Mbps (full duplex) for 10Base-T
  • 100Mbps (half duplex) / 200Mbps (full duplex) for 100Base-TX
Cabling:
  • CAT 3, 4, 5 UTP/STP for 10Base-T
  • CAT 5 UTP/STP for 100Base-TX
  • 62.5/125 SC-type fiber optic cable
LED's:
  • Power, Link, Transmit, Receive and 10/100Mbps status
Power:
  • External Power Supply, 600mA, 12V
Dimensions:
  • 201 x 122 x 30 mm / 7.9" x 4.8" x 1.2" (L x W x H)
Weight:
  • 685 g / 1.5 lb.
Temperature:
  • Operating: 0° to 50° C
  • Storage: -20° C to 80° C
Humidity:
  • 10% - 90% (non-condensing)
Certification:
  • FCC Class A, UL, CSA, CE

PACKAGE CONTENTS

    All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
