PoE Dome Network Camera

TV-IP252P   (Version B1.2R)

   Select Another Version
  • Tamper resistant interior wall and ceiling mount applications
  • Pan and tilt adjustable fixed position camera
  • Save installation costs with Power over Ethernet (PoE)
  • Program motion detection recording, email alerts, and more with complimentary software
  • Free apps

DISCONTINUED PRODUCT

The TV-IP252P (Version B1.2R) has been discontinued. It has been replaced by the TV-IP325PI (Version v1.0R). For a list of discontinued products, click here.

Utility

Drivers/Utility (Setup Wizard)
Filename: Utility_TV-IP252P_wizard.zip
SHA-1 Checksum: 021FD10010D9B7F26CF70FFD779D5DD06048CE2C
Date: 7/25/2017
File Size: 6.37 MB
Download
Utility (IP Setup)
Filename: Utility_IPSetup_V2.0.0.0.zip
SHA-1 Checksum: 8067F8FBC003E3475E66C4745FA2EC9C936F24EF
Date: 7/25/2017
File Size: 795.27 KB
Download

Firmware

Firmware

Version: V1.1.3
Date: 1/2014
Note:

  1. Support Internet Explorer 11

Note:

  1. Please do not save the camera's configuration file from the old firmware and restore it after the firmware upgrade
  2. After a successful firmware upgrade, please reset the camera to factory default and reconfigure the camera. We strongly recommend that you change the camera's administrator's account password.


Filename: FW_TV-IP252P(1.1.3).zip
SHA-1 Checksum: 9844F679807F5D2BA4F9247F120499DA982FE822
Date: 7/25/2017
File Size: 4.63 MB
Download

Software

TRENDnetVIEW Pro Software

Software Version: 2.5.9
Release Date: 4/2017
Notes:

  • Fixed TV-IP420P P/T issue

Filename: TRENDnetViewPro(2.5.9).zip
SHA-1 Checksum: 7CD1D9AE621816395E9FE9644B651F3696388215
Date: 7/25/2017
File Size: 41.15 MB
Download

Quick Installation Guide

Quick Installation Guide (European)
Filename: EUNL_QIG_TV-IP252P(B1.2R).pdf
Date: 7/9/2013
File Size: 5.26 MB
Download
Quick Installation Guide
Filename: QIG_TV-IP252P(B1.2R).pdf
Date: 7/9/2013
File Size: 1.96 MB
Download

TrendnetVIEW Pro Quick Installation Guide

TRENDnetVIEW Pro Quick Installation Guide (English)
Filename: EN_Web_TRENDnetVIEW_Pro.pdf
Date: 6/24/2014
File Size: 1.63 MB
Download
TRENDnetVIEW Pro Quick Installation Guide (Français)
Filename: FR_Web_TRENDnetVIEW_Pro.pdf
Date: 6/24/2014
File Size: 1.63 MB
Download
TRENDnetVIEW Pro Quick Installation Guide (Deutsch)
Filename: GE_Web_TRENDnetVIEW_Pro.pdf
Date: 6/24/2014
File Size: 1.62 MB
Download
TRENDnetVIEW Pro Quick Installation Guide (Español)
Filename: SP_Web_TRENDnetVIEW_Pro.pdf
Date: 6/24/2014
File Size: 1.62 MB
Download
TRENDnetVIEW Pro Quick Installation Guide (Pусский)
Filename: RU_Web_TRENDnetVIEW_Pro.pdf
Date: 6/24/2014
File Size: 1.64 MB
Download
TRENDnetVIEW Pro Quick Installation Guide (Polski)
Filename: POL_Web_TRENDnetVIEW_Pro.pdf
Date: 6/24/2014
File Size: 1.64 MB
Download
TRENDnetVIEW Pro Quick Installation Guide (Român)
Filename: RO_Web_TRENDnetVIEW_Pro.pdf
Date: 6/24/2014
File Size: 1.65 MB
Download
TRENDnetVIEW Pro Quick Installation Guide (Nederlands)
Filename: NL_Web_TRENDnetVIEW_Pro.pdf
Date: 6/24/2014
File Size: 1.63 MB
Download
TRENDnetVIEW Pro Quick Installation Guide (Magyar)
Filename: HU_Web_TRENDnetVIEW_Pro.pdf
Date: 6/24/2014
File Size: 1.64 MB
Download
TRENDnetVIEW Pro Quick Installation Guide (български)
Filename: BUL_Web_TRENDnetVIEW_Pro.pdf
Date: 6/24/2014
File Size: 1.62 MB
Download

TrendnetVIEW App Quick Installation Guide

TRENDnetVIEW App Quick Installation Guide (iOS)
Filename: TRENDnetVIEW_App_(iOS).pdf
Date: 6/24/2014
File Size: 1.90 MB
Download
TRENDnetVIEW App Quick Installation Guide (Android)
Filename: TRENDnetVIEW_App_(Android).pdf
Date: 6/24/2014
File Size: 1.90 MB
Download

User's Guide

User's Guide (TRENDnetVIEW Pro)
Filename: UG_TRENDnetVIEW_Pro.pdf
Date: 6/10/2014
File Size: 7.92 MB
Download
User's Guide
Filename: UG_TV-IP252P(V1).pdf
Date: 7/9/2013
File Size: 5.53 MB
Download

Product Images

TV-IP252P Product Photo (JPEG Image 1)
JPEG Image
File Size: : 344.82 KB
Date: : 7/9/2013
Download
TV-IP252P Product Photo (JPEG Image 2)
JPEG Image
File Size: : 173.99 KB
Date: : 7/9/2013
Download
TV-IP252P Product Photo (JPEG Image 3)
JPEG Image
File Size: : 317.93 KB
Date: : 7/9/2013
Download
TV-IP252P Product Photo (TIFF Image 4)
TIFF Image
File Size: : 4.56 MB
Date: : 7/9/2013
Download
TV-IP252P Product Photo (TIFF Image 5)
TIFF Image
File Size: : 2.02 MB
Date: : 7/9/2013
Download
TV-IP252P Product Photo (TIFF Image 6)
TIFF Image
File Size: : 3.58 MB
Date: : 7/9/2013
Download
ROHS compliant Non-Disposable
Lens
  • Focal length: 3.58 mm, F2.0
  • Board Lens
  • Sensor: 1/4” CMOS Sensor
  • Digital Zoom: 3x
Viewing Angle
  • Horizontal: 58°
  • Vertical: 45°
  • Diagonal: 69°
Minimum Illumination
  • 0.1 Lux @ F2.0
Pan/Tilt (Manually)
  • Pan: -175° ~ +175°
  • Tilt: 20~90°
Video Resolution
  • MPEG4: 640 x 480 up to 30 fps
  • MJPEG: 640 x 480 up to 30 fps
Audio
  • External microphone port for 3rd party microphone
  • Audio out port for 3rd party speakers
Standards
  • IEEE 802.3u
  • IEEE 802.3af
Device Interface
  • 10/100 Mbps PoE Ethernet
  • LED indicator
  • BNC port
  • Microphone in port
  • Audio out port
  • GPIO ports
  • Power port
Network Protocol
  • IPv4, UDP, TCP/ IP, ICMP
  • DHCP, NTP, DNS, DDNS, SMTP, FTP
  • Samba, Bonjour
  • HTTP, HTTPS
  • PPPoE
  • UPnP, RTSP, RTP, RTCP, SSL, 3GPP
Dimensions
  • 140 x 120 x 140 mm (5.2 x 4.7 x 5.5 in.)
Weight
  • 600 g (21.2 oz.)
Operating Temperature
  • 0 – 45°C (32 – 113°F)
Humidity
  • Max. 90% non-condensing
Power
  • Input: 100-240 V, 50/60 Hz, 0.5A
  • Output: 12V DC 1.5 A external power adapter (optional use)
  • Consumption: 8 Watts (max.)
Management Interface
  • Image Setting: brightness, saturation, sharpness, mirror (horizontal/vertical)
  • Recording: continuous, scheduled, and motion detetection
  • Event Trigger: motion detection triggers email and/or upload to FTP with real time snapshot
Management Settings
  • Up to 12 user accounts
  • Supports remote management
Compatibility
  • Internet Explorer 7.0 or higher
Camera Software: TRENDnetVIEW Pro
  • Supports up to 32 cameras
  • Multiple language support
  • Set recording options (motion detection, schedule, event trigger)
  • Search and playback
  • Custom viewing modes and options
  • Compatibility: Windows® 8, 7, Vista, XP, Windows Server 2003, 2008

PACKAGE CONTENTS
  • TV-IP252P
  • CD-ROM (Utility Software & User's Guide)
  • Multi-Language Quick Installation Guide
  • Network cable (1.8 m / 6 ft.)
  • Power adapter (12V DC, 1.5 A)
  • Camera mounting kit

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
