52-Port Gigabit Web-Based Smart Switch

TEG-2248WS

   Select Another Version
  • Manage port level speed, VLAN, QoS, Trunking and Mirroring
  • 2 x 10/100/1000Mbps and 48 x 10/100Mbps Auto-Negotiation and Auto-MDIX ports
  • 2 Mini-GBIC slots accommodates fiber networking

DISCONTINUED PRODUCT

The TEG-2248WS  has been discontinued. It has been replaced by the TEG-2248WS (Version C1.0R). For a list of discontinued products, click here.

Utility

Utility
Filename: Management_Utility.zip
SHA-1 Checksum: 43C887F69C87D01B12EB48DBF78CFC6E0F1D169D
Date: 7/25/2017
File Size: 529.98 KB
Download

Datasheet

Datasheet (English)
Filename: Spec_TEG-2248WS(English).pdf
Date: 12/20/2004
File Size: 1.16 MB
Download Email
Datasheet (Français)
Filename: Spec_TEG-2248WS(French).pdf
Date: 2/8/2005
File Size: 245.82 KB
Download Email
Datasheet (Deutsch)
Filename: Spec_TEG-2248WS(German).pdf
Date: 2/8/2005
File Size: 203.55 KB
Download Email
Datasheet (Español)
Filename: Spec_TEG-2248WS(Spanish).pdf
Date: 2/23/2005
File Size: 257.26 KB
Download Email

User's Guide

User's Guide
Filename: UG_TEG-2248WS.pdf
Date: 8/18/2004
File Size: 6.87 MB
Download

Product Images

TEG-2248WS Product Photo (JPEG Image 1)
JPEG Image
File Size: : 980.21 KB
Date: : 9/1/2004
Download
TEG-2248WS Product Photo (TIFF Image 2)
TIFF Image
File Size: : 2.26 MB
Date: : 9/1/2004
Download
ROHS compliant Non-Disposable
Hardware
Standards:
  • IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T, IEEE 802.3z 1000Base-SX/LX, IEEE 802.3x Full Duplex Flow Control
Network Media:
  • Ethernet: UTP/STP Cat. 3, 4, 5
  • Fast Ethernet: UTP/STP Cat. 5
  • Gigabit: UTP/STP Cat. 5
Protocol /Topology:
  • CSMA/CD, Star
LAN Ports:
  • 48 x 10/100Mbps Auto Negotiation, Auto-MDIX Fast Ethernet ports
  • 2 x 10/100/1000Mbps Auto Negotiation, Auto MDIX Gigabit ports
  • 2 x Mini GBIC ports for optional Mini-GBIC modules
Data Transfer Rate:
  • Ethernet: 10Mbps/20Mbps (Half-Duplex/Full-Duplex)
  • Fast Ethernet: 100Mbps/200Mbps (Half-Duplex/Full-Duplex)
  • Gigabit Ethernet: 2000Mbps (Full-Duplex)
Address Table:
  • 4K Entries
Data RAM Buffer:
  • 1536KBytes
Diagnostic LEDs:
  • Per Unit: Power, System
  • Per Fast Ethernet Port: Link/ACT
  • Per Cooper Gigabit Port: Link/ACT, Speed (1000M-Green, 100M-Amber)
  • Per Mini-GBIC Gigabit Port: Link/ACT
Power/Consumption:
  • 100-240V AC, 50/60Hz Internal Universal Power Supply / 24 watts (max)
Dimensions (W x D x H):
  • 440 x 200 x 44 mm (17.32" x 7.9" x 1.73")
Weight:
  • 2.6kg (5.78lbs)
Temperature:
  • Operating : 0° ~ 40° C (32° ~ 104° F)
  • Storage: -10° ~ 70° C (14? ~ 158° F)
Humidity:
  • 10% ~ 90% (no-condensing)
Certifications:
  • FCC Class A, CE Class A

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
