VoIP Bluetooth Phone with Bluetooth Adapter (for SKYPE™)
TVP-SP1BK (Version 1.0)
- Reduce conference call expenses
- Make wireless crystal clear calls anywhere you want with an Internet connection
- Enjoy interference free Bluetooth™ wireless calling
- View, manage and call Skype™ contacts directly from this wireless phone
DISCONTINUED PRODUCT
The TVP-SP1BK (Version 1.0) has been discontinued. For a list of discontinued products, click here.Utility
 | TVP-SP1BK Vista Compatible Utility/Driver Utility Version: 10.1.0.238 Driver Version: 1.00 Release Date: 2/15/2007 |
Installation Instruction
- Download and Unzip the Driver_Utility_TVPSP1BK_Vista.zip file
- Go to the unzipped folder and double click the Setup.exe file to start installation
- Follow the standard Quick Installation Guide to install and setup the TVP-SP1BK on a Vista machine
- Installation complete
TVP-SP1BK (Version v1.1R) supports and comes with x64 drivers
File name: Driver_Utility_TVP-SP1BK.zip
Release Note:
Date: 12/2008
- Fix the memory access violation error on Vista SP1.
Datasheet
Quick Installation Guide
User's Guide
Frequently Asked Questions (FAQ)
Product Images
| Hardware | |
| Standards | Class I Bluetooth v2.0 with EDR |
| Headset Interface | Mini-B USB Connector for charging |
| Adapter Interface | USB 1.1, 2.0 / External Dipole Antenna |
| Display | 96 x 64 pixel (STN LCD with back light) |
| LED Indicator | Headset Status (Active, Standby, Sleep) |
| Battery | 3.6V 700mAh Lithium-ion Rechargeable Battery |
| Cable | Type A to Mini-B USB Cable (1m / 3ft.) for charging |
| Power Consumption | Standby Time : 60+ hours |
| Dimensions | Headset: 143.5 x 45 x 22 mm (5.6 x 1.78 x 0.9 in.) |
| Unit Weight | Headset: 100 g (3.5 oz.) / Adapter: 10 g (0.35 oz.) |
| Temperature | Operation: 0°~ 50°C (32°F~122°F); Storage: -20°~ 70°C (-4°F~158°F) |
| Humidity | 10~90% |
| Certification | CE, FCC |
| Phone Features | |
Volume | Volume up: Vol +; Volume down: Vol - |
Skype Support | - Sync Contact list, History, SkypeIn, SkyOut |
| Bluetooth | |
Frequency | 2.4~2.4835 GHz ISM Band |
Spread Spectrum | Frequency Hopping and Adaptive Frequency Hopping |
RF Output Power | 17dBm (typical) |
Receiving Sensitivity | -90dBm@0.1%BER ( typical ) |
Date Range | Up to 100m (328 ft.) depends on environment |
| ClearSky ™ Bluetooth VoIP Phone Kit | |
PACKAGE CONTENTS |
|
