Wireless Network Settings

Use this section to configure the wireless settings for your TRENDware MIMO Wireless Router. Please note that changes made on this section may also need to be duplicated on your Wireless Client.

To protect your privacy you can configure wireless security features. This device supports three wireless security modes including: WEP, WPA-Personal, and WPA-Enterprise. WEP is the original wireless encryption standard. WPA provides a higher level of security. WPA-Personal does not require an authentication server. The WPA-Enterprise option requires an external RADIUS server.

Wireless Radio Status

Wireless Radio : ON OFF

Basic Wireless Settings

Wireless Network Name : (Also called the SSID)
Visibility Status : Visible Invisible
Auto Channel Select :
Channel :
Transmission Rate : (Mbit/s)
802.11 Mode :
Super G™ Mode :

Wireless Security Mode

Security Mode : None WEP WPA-Personal WPA-Enterprise


WEP is the wireless encryption standard. To use it you must enter the same key(s) into the router and the wireless stations. For 64 bit keys you must enter 10 hex digits into each key box. For 128 bit keys you must enter 26 hex digits into each key box. A hex digit is either a number from 0 to 9 or a letter from A to F. For the most secure use of WEP set the authentication type to "Shared Key" when WEP is enabled.

You may also enter any text string into a WEP key box, in which case it will be converted into a hexadecimal key using the ASCII values of the characters. A maximum of 5 text characters can be entered for 64 bit keys, and a maximum of 13 characters for 128 bit keys.

WEP Key Length : (length applies to all keys)
WEP Key 1 :
WEP Key 2 :
WEP Key 3 :
WEP Key 4 :
Default WEP Key :
Authentication :


WPA requires stations to use high grade encryption and authentication. NOTE: WDS will not function with WPA security.

WPA Mode :
Cipher Type :
Group Key Update Interval : (seconds)

Pre-Shared Key

Pre-Shared Key :

EAP (802.1x)

When WPA enterprise is enabled, the router uses EAP (802.1x) to authenticate clients via a remote RADIUS server.

Authentication Timeout : (minutes)
RADIUS server IP Address :
RADIUS server Port :
RADIUS server Shared Secret :
MAC Address Authentication :

Optional backup RADIUS server:

Second RADIUS server IP Address :
Second RADIUS server Port :
Second RADIUS server Shared Secret :
Second MAC Address Authentication :
