Product Families » Internet Cameras » TV-IP322P
Outdoor PoE Megapixel Day/Night Internet Camera
TV-IP322P (Version v1.0R)
  • Narrow field of vision for long distance monitoring
  • Night vision up to 20 meters (66 ft.)
  • Outdoor installation ready with an IP66 weather proof rating
  • H.264 Megapixel resolution at up to 1280 x 1024
  • Save installation cost with Power over Ethernet (PoE)
  • Program motion detection recording and email alerts with complimentary software
SecurView IP Camera Critical
Firmware Update Available



TV-IP322P
Click on image to enlarge

The SecurView Pro Outdoor PoE Megapixel Day/Night Internet Camera, model TV-IP322P, provides powerful Megapixel night vision in complete darkness for up to 20 meters (66 feet).

This camera is outdoor installation ready with an IP66 rated weather proof and vandal proof outdoor enclosure. No need to install this camera near a power source, power and data are received through a single Ethernet cable using Power over Ethernet (PoE) technology.

Record 1280 x 1024 pixel (SXGA) H.264 video at up to 15 frames per second (fps) or 640 x 480 pixel (VGA) resolution at up to 30 fps. Manage up to 32 TRENDnet cameras with the included complimentary camera management software. Advanced features include motion detection recording, email alerts, scheduled recording sessions, H.264/MPEG-4 image compression, 3GPP support, Samba client support, Input/Output ports to network to alarm systems, date-and-time and other text overlays, mask overlays to conceal sensitive areas, and digital zoom. A wall/ceiling mounting kit is included and a sun visor shields the camera from direct sunlight.


RoHS Compliant

  • Ready for outdoor installation with an IP66 rated weather proof and vandal proof outdoor housing
  • IEEE 802.3af PoE compliant device
  • 1 x 10/100Mbps PoE Auto-MDIX RJ-45 port
  • Optional power port for non-PoE installations
  • SD/SDHC card slot *
  • Input/Output ports (GPIO) to network to alarm systems
  • High quality H.264, MPEG-4, and MJPEG video recording
  • Resolution up to 1280 x 1024 pixels at up to 15 frames per second (fps) and 640 x 480 pixels at up to 30 fps
  • Stream Internet camera video to a 3GPP compatible wireless device
  • Powerful infrared bulbs enable recording in complete darkness for distances up to 20 meters (66 feet)
  • Two way audio is enabled by installing optional third party microphone and speakers
  • Dynamic DNS support
  • Images controls: brightness, contrast, saturation and mirror (horizontally/vertical)
  • Time, date, and other text overlays
  • Mask overlays conceal sensitive areas
  • Supports TCP/IP networking, SMTP Email, HTTP, and other Internet protocols
  • Record streaming video to your computer or Network Storage device with Samba support
  • Three motion detection windows with just-in-time snapshot, motion detection triggered email alerts, and image upload to FTP
  • Send instant messages to Jabber client via Jabber Server
  • Supports Quality of Service (QoS) with Differentiated Services Code Point (DSCP)
  • Quick Universal Plug and Play (UPnP) installation
  • Complimentary SecurView Pro software: manage up to 32 cameras**
  • 3-year limited warranty

* SD card sold separately
* Monitoring multiple cameras may require a high performance CPU

Camera
General Sensor: 1/3" Megapixels color CMOS sensor
Resolution: 1280 x 1024 pixels
Board Lens
Focal Length: 12mm
Aperture (F/No): F1.8
Minimum illumination: 0 Lux (Night vision)
Viewing Angle:
  • Diagonal: 32 degree
  • Horizontal: 27 degree
  • Vertical: 18 degree
Image & Video Compression: H.264, MPEG-4, and MJPEG
Exposure/white balance/gain control : automatic
Built-in ICR
Audio External microphone in
Sensitivity: -48dB +/- 3dB
Frequency:50~16000Hz
S/N: >60dB
Format: PCM/AMR
Pan/Tilt/Zoom Protocol: Pelco D, Pelco P
32 presets
Auto Patrol
GPIO Ground, GPIO in/out, RS485, 12V DC, 24V AC
SD Slot Supports SD/SDHC (up to 32GB)
Hardware
Network IEEE 802.3u 10/100Mbps Fast Ethernet
IEEE 802.3af PoE
LED Power, Link
IR Wavelength 850nm
Reset Button Reboot or restore to factory default
Power Over Ethernet PoE Power on RJ-45 pin 3,6 for Power+ and pin 1,2 for Power-
Power Consumption 9.5 Watts max.
Power 12 V DC, 1.5 A external power adapter (for non-PoE installations)
Dimension 235 x 110 x 89 mm (9.3 x 4.3 x 3.5 in.)
Weight 1.5 kg (3.2 lb)
Operating Condition
  • Temperature : -20°C ~ 60°C (-4°F ~ 140°F)
  • Wind Velocity: 130km/hr
  • Humidity: Max. 90% (non-condensing)
Certifications CE, FCC, IP66
Requirement
Management Interface Internet Explorer 6.0 or above
To Run SecurView Pro Windows 7 (32/64-bit), Vista (32/64-bit), XP (32/64-bit)
SecurView Pro Channel: supports up to 32 cameras
Record/Playback/Motion Detection
Network Protocols TCP/IP, IPv4, IPv6, UDP, ICMP, DHCP, NTP, DNS, DDNS, SMTP, FTP, HTTP, HTTPs, Samba, PPPoE, UPnP, Bonjour, RTP, RTSP, and RTCP
Management
Remote Remote management supported
Backup / Restore Save/retrieve configuration files
Settings
Image Brightness, saturation, sharpness, and mirror (horizontal/vertical)
Video
  • Encoding type: H.264, MPEG-4, MJPEG
  • Compression: 5 levels
  • Resolution/Frame Rate:
    • SXGA (1280 x 1024) up to 15fps
    • VGA (640x480) up to 30fps
    • QVGA (320x240) up to 30fps
    • QQVGA (160x120) up to 30fps
  • Multi-Stream
    • H.264: SXGA, VGA, QVGA, QQVGA
    • MPEG4: VGA, QVGA, QQVGA
    • MJPEG: SXGA, VGA, QVGA, QQVGA
Recording Recording type: continuous, schedule, or motion detection with software
Event Management Event trigger: motion, GPIO, schedule
Store video file to SD card
Send Instant message to Jabber client via Jabber server
QoS DSCP
Port Settings HTTP port: 80 (default)
Digital Zoom 3x
Dynamic DNS Yes
Time Synchronize with NTP server or set time/date manually
SMTP SMTP mail supported up to 2 destination accounts
System Log 100 entries (max.)

TV-IP322P

Information provided in this document pertain to TRENDnet products and is subject to change at any time, without notice.

Additional Info
Critical Firmware update available
Email a Friend
Datasheet
Quick Installation Guide
Downloads
View Knowledgebase
View Emulator
Register Your Product
Package Contents
  • TV-IP322P
  • Multi-language Quick Installation Guide
  • CD-ROM (Utility & User’s Guide)
  • Power adapter (12 V DC, 1.5 A)
  • Network Cable (1.5 m/ 5 ft.)
  • GPIO Adapter
  • Spiral Cable Wrap
  • Camera Bracket
