The Wireless N Home Router delivers the highest level of security, 12x the speed and 4x the range of wireless g products. Install the product in minutes with Easy-Go installation and seamlessly stream live media, download files, play games and talk Online all at the same time and with no wireless lag.
The latest in wireless encryption and a secure firewall provide the ultimate in wired and wireless security. Advanced MIMO antenna technology delivers superior range and eliminates dead spots. A quick and intuitive installation process, remote management capabilities and a 3-year warranty make this product well suited for your most demanding networking needs.
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network traffic, building materials and other conditions.
- Wi-Fi compliant with IEEE 802.11n and IEEE 802.11b/g standards
- 4 x 10/100Mbps Auto-MDIX LAN port and 1 x 10/100Mbps WAN port (Internet)
- Supports Cable/DSL modems with Dynamic IP, Static IP, PPPoE, PPTP, L2TP & BigPond connection types
- High-speed up to 300Mbps data rate using IEEE 802.11n connection
- 2 external antennas support high speed performance and great coverage with MIMO technology
- Firewall features Network Address Translation (NAT), and Stateful Packet Inspection (SPI) protects against DoS attacks
- Support Wi-Fi Protected Setup (WPS) for easy connection
- Universal Plug and Play (UPnP) and Application Level Gateway support for internet applications such as email, FTP, gaming, remote desktop, Net Meeting, telnet and more
- Provides additional security of enable/disable wireless SSID, Internet Access Control (MAC Address, Domain & IP Filtering)
- Easy management via web browser and remote management
- Supports 64/128-bit WEP, WPA/WPA2 and WPA-PSK/WPA2-PSK
- Wi-Fi Multimedia (WMM) Quality of Service (QoS) supported
- Multiple VPN Pass-through sessions for IPSec, PPTP and L2TP
- Works with Windows 95/98/NT/2000/XP/2003 Server/Vista, Linux and Mac OS
- Coverage up to 100 meters (330ft.) indoor;(depends on the environment)
- Coverage up to 300 meters (980ft.) outdoor;(depends on the environment)
- 3- year warranty
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network traffic, building materials and other conditions.
Hardware |
Standards | - Wired: IEEE 802.3 (10Base-T), IEEE 802.3u(100Base-TX)
- Wireless: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n(draft 2.0)
|
WAN | 1 x 10/100Mbps Auto-MDIX port (Internet) |
LAN | 4 x 10/100Mbps Auto-MDIX ports |
WPS Button | Enable Wi-Fi Protected Setup function |
Connection Type | Dynamic IP, Static (Fixed) IP, PPPoE, PPTP, L2TP, BigPond |
UPnP | UPnP IGD 1.0 compliant |
DMZ | DMZ host & Virtual Servers |
DNS | Static or WAN assigned DNS servers; 3 verified services for DDNS |
Internet Access Control | MAC Address Filter, Domain/URL Filter, Protocol/IP Filter |
Logging | 5 types event logging Email report |
LED Indicator | Power, LAN1~LAN4, WAN, WLAN |
Power Adapter | 5V DC, 2.5A external power adapter |
Power Consumption | 7W |
Dimension (L x W x H) | 150 x 110 x 30 mm (5.9x 4.3 x 1.1 inches) |
Weight | 245g (8.6oz) |
Temperature | - Operation: 0°~ 40°C (32°F~ 104°F);
- Storage: -10°~ 70°C (14°F~158 °F)
|
Humidity | Max. 90% (non-condensing) |
Certifications | CE, FCC |
Wireless |
Frequency | 2412~2484MHz ISM band |
Antenna | 2 x 2dBi Detachable dipole antenna |
Media Access Protocol | CSMA/CA with ACK |
Data Rate | - 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps
- 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps
- 802.11n: up to 300Mbps
|
Security | - WEP(HEX/ASCII): 64/128-bit
- WPA(AES/TKIP):WPA/WPA2, WPA-PSK/WPA2-PSK
- Enable/Disable broadcast SSID
|
Output Power | - 802.11b: 17dBm (typical)
- 802.11g: 13dBm (typical)
- 802.11n: 13dBm (typical)
|
Receiving Sensitivity | - 802.11b: -85dBm (typical) @ 11Mpbs
- 802.11g: -68dBm (typical) @ 54Mbps
- 802.11n: -62dBm (typical) @300Mbps
|
Channels | 1~ 11 (US), 1~13 (EU) |
PACKAGE CONTENTS |
- TEW-632BRP
- Multi-language quick installation guide
- Easy-Go installation
CD-ROM - Power adapter
(5V DC, 2.5A) - Cat. 5 Ethernet cable (1.5m/5ft.)
|
All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
