Hardware |
Standards | - Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX), IEEE 802.3ab (1000Base-T)
- Wireless: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n (draft 2.0), IEEE 802.11e QoS
|
WAN | 1 x 10/100/1000Mbps Auto-MDIX Gigabit port (Internet) |
LAN | 4 x 10/100/1000Mbps Auto-MDIX Gigabit port |
Slide Switch | Turn on/off wireless LAN |
WPS Button | Enable WPS function (PIN setup) |
Connection Type | Dynamic IP, Static (Fixed) IP, PPPoE, PPTP, L2TP, BigPond |
NAT Firewall | 3K configurable NAT entries; Restricted NAPT IP ranges, port ranges & schedule Pre-defined game hosting configurations Port triggering for 24 special applications ALG support (enable/disable support) – PPTP, IPSec, RTP/RTSP, AOL, FTP, ICMP, WMP/MMS, NetMeeting, SIP, MSN Messenger, Wake on LAN |
SPI Firewall | Up to 24 rules; Cyber attack protection – verified against over 2000 attacks |
Multicast Stream | Enable/Disable control support |
UPnP | UPnP IGD compliant |
DMZ | DMZ host, 24 configurable virtual servers & game servers |
DNS | Static or WAN assigned DNS servers; 10 verified services for DDNS |
Internet Access Control | Policy based parental control; Time based internet access; Port range/service filtering; Dynamic URL filtering; Internet domain restriction; 32 user defined schedules, 24 MAC Address Filter Entries |
Logging | 3 types & 3 severities event logging; up to 1K entries Email report logging on schedule or log full |
LED Indicator | Power, LAN1~LAN4, WAN, WLAN |
Power Adapter | 12V DC, 1A external power adapter |
Power Consumption | 779mA |
Dimension (L x W x H) | 150 x 162 x 25 mm (5.9 x 6.4 x 1 inches) |
Weight | 335g (11.8oz) |
Temperature | - Operation: 0°~ 40°C (32°F~ 104°F)
- Storage: -20°~ 60°C (-4°F~140 °F)
|
Humidity | Max. 90% (non-condensing) |
Certifications | CE, FCC |
Wireless |
Frequency | 2.412 ~ 2.462 GHz (FCC); 2.412 ~ 2.472 GHz (ETSI) |
Antenna | 3 x 4dBi fixed dipole antenna |
Media Access Protocol | CSMA/CA with ACK |
Data Rate | - 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps
- 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps
- 802.11n (draft 2.0): up to 300Mbps
|
Security | - Encryption: hardware AES/TKIP, 64/128-bit WEP (Hex/Passphrase, for 11b/g)
- 802.1X/EAP: EAP-TLE,EAP-TTLE/MSCHAPv2, PEAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC
- WPA: WPA/WPA2, WPA-PSK/WPA2-PSK (AES-11b/g/n, TKIP-11b/g)
- WPS: support PIN and PBC
- SSID broadcast control
|
Output Power | - 802.11b: 18dBm (typical)
- 802.11g: 15dBm (typical)
- 802.11n (draft 2.0): 6dBm (typical) with HT20 or HT40
|
Receiving Sensitivity | - 802.11b: -84dBm (typical) @ 11Mpbs
- 802.11g: -73dBm (typical) @ 54Mbps
- 802.11n (draft 2.0) : -69dBm (typical) with HT20 or HT40
|
Channels | 1~ 11 (US), 1~13 (EU) |
